Titan
Carbon Steel Socket Weld Y Strainer - Class 600
- SKU:
- YS82-CS
- Availability:
- Usually Ships Same Day
- Weight:
- 0.00 LBS
Description
Titan YS82-CS Carbon Steel Socket Weld Y Strainer - Class 600
Titan Flow Control YS82-CS carbon steel socket weld Y strainers provide high-pressure debris removal for compatible industrial piping systems while helping protect pumps, meters, valves, spray nozzles, compressors, turbines, and other downstream equipment.
Select the required nominal pipe size from the product options above. The selected variation determines the Titan part code, GetPipe selling price, shipping weight, net cost, and size-specific product information.
Product Highlights
- Titan Flow Control model YS82-CS
- ASTM A216 Grade WCB carbon steel body
- Socket weld end connections
- ASME Class 600 design
- 1,480 psi WOG non-shock pressure rating at 100°F
- Cap-cover design in sizes 1/4" through 2"
- Large straining capacity
- Precision-machined screen seats
- Self-cleaning capability with an appropriate blow-off arrangement
- Type 304 stainless steel stocked screen and perforation material
- Available in nominal pipe sizes from 1/4" through 2"
Technical Specifications
| Manufacturer | Titan Flow Control |
|---|---|
| Model | YS82-CS |
| Product Type | Y / Wye Strainer |
| Body Material | Carbon Steel - ASTM A216 Grade WCB |
| End Connection | Socket Weld |
| ASME Rating | Class 600 |
| Pressure Rating | 1,480 psi WOG non-shock at 100°F |
| Stocked Screen / Perforation Material | Type 304 Stainless Steel |
| Available Sizes | 1/4" through 2" |
High-Pressure Socket Weld Protection
The YS82-CS combines a rugged ASTM A216 Grade WCB carbon steel body with socket weld ends for high-pressure industrial piping. Process flow passes through the internal straining element, which captures debris before it reaches sensitive downstream equipment.
Routine inspection and cleaning of the straining element helps maintain flow and limit pressure loss across the strainer.
Straining Element Options
Titan identifies Type 304 stainless steel as the material used for stocked mesh and perforation selections on the YS82-CS series. Stocked mesh selections include 10, 20, 30, 40, 60, 80, and 100 mesh, with multiple stocked perforation sizes also available. If your service requires a specific filtration opening, contact GetPipe.com before ordering so the required configuration can be confirmed.
Common Applications
Industrial Piping
- High-pressure process piping
- Pump and meter protection
- Valve protection
- Utility systems
Equipment Protection
- Spray nozzles
- Compressors
- Turbines
- Other compatible downstream equipment
Titan Product Resources
Use the manufacturer documents below for model-specific technical information, installation guidance, maintenance procedures, and selection assistance.
Need Help Selecting a Titan Carbon Steel Socket Weld Y Strainer?
Our industrial PVF specialists can help confirm nominal pipe size, socket weld requirements, pressure class, straining element, media compatibility, service conditions, and product availability.
Frequently Asked Questions
What is the Titan YS82-CS?
The YS82-CS is an ASTM A216 Grade WCB carbon steel Y strainer with socket weld ends and an ASME Class 600 rating.
What is the pressure rating?
Titan rates the YS82-CS at 1,480 psi WOG non-shock at 100°F.
What sizes are available?
Titan publishes the YS82-CS from 1/4" through 2".
What screen material is used for stocked configurations?
Titan identifies Type 304 stainless steel for stocked mesh and perforation selections.
How is this different from the YS81-CS?
The YS82-CS uses socket weld end connections, while the YS81-CS uses threaded end connections. Both are Class 600 carbon steel Y strainers.
Important Ordering Notes
- Select the required nominal pipe size before adding the product to your cart.
- The selected variation determines the Titan part code, price, shipping weight, and net cost.
- Confirm socket dimensions and welding requirements before installation.
- Confirm required mesh or perforation when the standard configuration does not suit the application.
- Confirm pressure, temperature, media compatibility, and applicable code requirements before use.
- Review Titan's current specification sheet and IOM manual before installation or maintenance.
