Titan
Stainless Steel Socket Weld Y Strainer - 800 WOG
- Availability:
- Usually in Stock – Ships Quickly
- Weight:
- 0.00 LBS
Description
Titan YS80S-SS Stainless Steel Socket Weld Y Strainer - 800 WOG
Titan Flow Control YS80S-SS stainless steel socket weld Y strainers provide corrosion-resistant debris removal for compatible high-pressure piping systems while helping protect pumps, meters, valves, spray nozzles, compressors, turbines, and other downstream equipment.
Select the required nominal pipe size from the product options above. The selected variation determines the Titan part code, GetPipe selling price, shipping weight, net cost, and size-specific product information.
Product Highlights
- Titan Flow Control model YS80S-SS
- ASTM A351 Grade CF8M stainless steel body
- Socket weld end connections
- 800 WOG design
- 800 psi WOG non-shock pressure rating at 100°F
- Corrosion-resistant stainless steel construction
- Large straining capacity
- Precision-machined screen seats
- Self-cleaning capability with threaded cap access
- Type 304 stainless steel stocked screen and perforation material
- Available in nominal pipe sizes from 1/4" through 3"
Technical Specifications
| Manufacturer | Titan Flow Control |
|---|---|
| Model | YS80S-SS |
| Product Type | Y / Wye Strainer |
| Body Material | Stainless Steel - ASTM A351 Grade CF8M |
| End Connection | Socket Weld |
| ASME Rating | 800 WOG |
| Pressure Rating | 800 psi WOG non-shock at 100°F |
| Stocked Screen / Perforation Material | Type 304 Stainless Steel |
| Available Sizes | 1/4" through 3" |
High-Pressure Socket Weld Protection
The YS80S-SS combines ASTM A351 Grade CF8M stainless steel construction with socket weld end connections for compact, corrosion-resistant pipeline protection. Process flow passes through the internal straining element, which captures debris before it reaches sensitive downstream equipment.
Routine inspection and cleaning of the straining element helps maintain flow and limit pressure loss across the strainer.
Straining Element Options
Titan lists Type 304 stainless steel stocked mesh selections of 10, 20, 30, 40, 60, 80, and 100 mesh. Stocked perforation selections include 1/32", 3/64", 1/16", 1/8", 5/32", and 1/4". If your service requires a specific mesh or perforation, contact GetPipe.com before ordering so the required configuration can be confirmed.
Common Applications
Industrial Piping
- Chemical processing
- Oil and gas systems
- High-pressure utility piping
- Pump and meter protection
Equipment Protection
- Valves
- Spray nozzles
- Compressors
- Turbines and other compatible downstream equipment
Titan Product Resources
Use the manufacturer documents below for model-specific technical information, installation guidance, maintenance procedures, and selection assistance.
Need Help Selecting a Titan Stainless Steel Socket Weld Y Strainer?
Our industrial PVF specialists can help confirm nominal pipe size, socket weld requirements, pressure requirements, straining element, media compatibility, service conditions, and product availability.
Frequently Asked Questions
What is the Titan YS80S-SS?
The YS80S-SS is an ASTM A351 Grade CF8M stainless steel Y strainer with socket weld ends for high-pressure debris removal in compatible piping systems.
What is the pressure rating?
Titan rates the YS80S-SS at 800 psi WOG non-shock at 100°F.
How is the YS80S-SS different from the YS80T-SS?
The YS80S-SS uses socket weld end connections, while the YS80T-SS uses threaded end connections. Both are stainless steel 800 WOG Y strainers.
What sizes are available?
Titan publishes the YS80S-SS from 1/4" through 3".
Can a specific screen or perforation be selected?
Yes. Contact GetPipe.com when a specific filtration opening is required so the appropriate Titan straining element can be confirmed.
Important Ordering Notes
- Select the required nominal pipe size before adding the product to your cart.
- The selected variation determines the Titan part code, price, shipping weight, and net cost.
- Confirm socket dimensions and welding requirements before installation.
- Confirm required screen or perforation when the application requires a specific level of filtration.
- Confirm pressure, temperature, media compatibility, and applicable code requirements before use.
- Review Titan's current specification sheet and IOM manual before installation or maintenance.
