Titan
Carbon Steel Flanged Y Strainer - Class 150
- SKU:
- YS61-CS
- Availability:
- Usually Ships Same Day
- Weight:
- 0.00 LBS
Description
Titan YS61-CS Carbon Steel Flanged Y Strainer - Class 150
Titan Flow Control YS61-CS carbon steel flanged Y strainers remove pipeline debris while helping protect pumps, meters, control valves, spray nozzles, compressors, turbines, steam equipment, and other downstream components in industrial piping systems.
Select the required nominal pipe size from the product options above. The selected variation determines the Titan part code, GetPipe selling price, shipping weight, net cost, and size-specific product information.
Product Highlights
- Titan Flow Control model YS61-CS
- ASTM A216 Grade WCB carbon steel body
- Raised-face flanged end connections
- ASME Class 150 design
- 285 psi WOG non-shock pressure rating at 100°F
- Inlet and outlet gauge taps
- Large straining capacity
- Precision-machined screen seats
- Self-cleaning capability with an appropriate blow-off arrangement
- Epoxy-painted exterior
- Optional cover designs available from Titan
- GetPipe variants from 1/2" through 12"
Technical Specifications
| Manufacturer | Titan Flow Control |
|---|---|
| Model | YS61-CS |
| Product Type | Y / Wye Strainer |
| Body Material | Carbon Steel - ASTM A216 Grade WCB |
| End Connection | Flanged - Raised Face |
| ASME Rating | Class 150 |
| Pressure Rating | 285 psi WOG non-shock at 100°F |
| Body Finish | Epoxy Painted |
| Stocked Screen / Perforation Material | Type 304 Stainless Steel |
| Standard Water Screen - 1/2" through 4" | 1/16" Perforation |
| Standard Water Screen - 5" through 12" | 1/8" Perforation |
| GetPipe Variants | 1/2" through 12" |
How a Flanged Y Strainer Works
Process flow passes through the internal cylindrical straining element, which retains debris before it can reach downstream equipment. The Y-shaped body provides a collection area for solids and access to the straining element for inspection and cleaning.
Titan provides inlet and outlet gauge taps on this series so differential pressure can be monitored as the screen loads. Routine inspection and cleaning help maintain system flow and limit excessive pressure loss.
Straining Element Options
For standard water service, published configurations use 1/16" perforation on sizes 1/2" through 4" and 1/8" perforation on sizes 5" through 12". Titan also offers stocked mesh and alternate perforation selections in Type 304 stainless steel. If your application requires a specific filtration opening, contact GetPipe.com before ordering so the required configuration can be confirmed.
Common Applications
Industrial & Utility Piping
- Process water systems
- Pump and meter protection
- Control-valve protection
- Utility piping
Equipment Protection
- Steam systems within published limits
- Spray nozzles
- Compressors and turbines
- Other compatible downstream equipment
Titan Product Resources
Use the manufacturer documents below for model-specific technical information, installation guidance, maintenance procedures, and selection assistance.
Need Help Selecting a Titan Carbon Steel Flanged Y Strainer?
Our industrial PVF specialists can help confirm nominal pipe size, flange class, straining element, pressure and temperature requirements, media compatibility, and product availability.
Frequently Asked Questions
What is the Titan YS61-CS?
The YS61-CS is an ASTM A216 Grade WCB carbon steel, raised-face flanged Y strainer with an ASME Class 150 rating.
What is the pressure rating?
Titan rates the YS61-CS at 285 psi WOG non-shock at 100°F.
What is the standard water perforation?
Published standard water configurations use 1/16" perforation through 4" and 1/8" perforation from 5" through 12".
Can other screen sizes be ordered?
Yes. Titan offers multiple stocked mesh and perforation selections. Contact GetPipe.com for non-standard filtration requirements.
Why are gauge taps provided?
Gauge taps allow inlet and outlet pressure to be monitored so differential pressure across the straining element can be evaluated as debris accumulates.
Important Ordering Notes
- Select the required nominal pipe size before adding the product to your cart.
- The selected variation determines the Titan part code, price, shipping weight, and net cost.
- Confirm mating flange dimensions, pressure class, gasket, and bolting requirements before installation.
- Standard water perforation changes at 5". Confirm filtration requirements before ordering.
- Sizes exceeding parcel-shipping limits may ship by freight.
- Confirm pressure, temperature, media compatibility, installation orientation, and applicable code requirements before use.
- Review Titan's current specification sheet and IOM manual before installation or maintenance.
