Titan
Carbon Steel Threaded Y Strainer - Class 600
- SKU:
- YS81-CS
- Availability:
- Usually Ships Same Day
- Weight:
- 0.00 LBS
Description
Titan YS81-CS Carbon Steel Threaded Y Strainer - Class 600
Titan Flow Control YS81-CS carbon steel threaded Y strainers provide high-pressure debris removal for compatible industrial piping systems while helping protect pumps, meters, valves, spray nozzles, compressors, turbines, and other downstream equipment.
Select the required nominal pipe size from the product options above. The selected variation determines the Titan part code, GetPipe selling price, shipping weight, net cost, and size-specific product information.
Product Highlights
- Titan Flow Control model YS81-CS
- ASTM A216 Grade WCB carbon steel body
- Threaded end connections
- ASME Class 600 design
- 1,480 psi WOG non-shock pressure rating at 100°F
- Cap-cover design for sizes 1/4" through 2"
- Large straining capacity
- Precision-machined screen seats
- Self-cleaning capability when installed with an appropriate blow-off arrangement
- Epoxy-painted exterior
- Available in nominal pipe sizes from 1/4" through 2"
Technical Specifications
| Manufacturer | Titan Flow Control |
|---|---|
| Model | YS81-CS |
| Product Type | Y / Wye Strainer |
| Body Material | Carbon Steel - ASTM A216 Grade WCB |
| End Connection | Threaded |
| ASME Rating | Class 600 |
| Pressure Rating | 1,480 psi WOG non-shock at 100°F |
| Body Finish | Epoxy Painted |
| Stocked Screen / Perforation Material | Type 304 Stainless Steel |
| Available Sizes | 1/4" through 2" |
High-Pressure Strainer Protection
The YS81-CS is designed for higher-pressure piping where a rugged carbon steel body and Class 600 rating are required. Process flow passes through the internal straining element, which retains debris before it can reach sensitive downstream equipment.
Routine inspection and cleaning of the straining element helps maintain flow and control pressure loss across the strainer.
Straining Element Options
Titan identifies Type 304 stainless steel for stocked mesh and perforation selections used with the YS81-CS family. If your service requires a specific mesh or perforation, contact GetPipe.com before ordering so the required configuration can be confirmed.
Common Applications
Industrial Piping
- High-pressure process piping
- Pump and meter protection
- Valve protection
- Utility systems
Equipment Protection
- Spray nozzles
- Compressors
- Turbines
- Other compatible downstream equipment
Titan Product Resources
Use the manufacturer documents below for model-specific technical information, installation guidance, maintenance procedures, and selection assistance.
Need Help Selecting a Titan Carbon Steel Y Strainer?
Our industrial PVF specialists can help confirm nominal pipe size, pressure class, straining element, media compatibility, service conditions, and product availability.
Frequently Asked Questions
What is the Titan YS81-CS?
The YS81-CS is an ASTM A216 Grade WCB carbon steel threaded Y strainer with an ASME Class 600 rating.
What is the pressure rating?
Titan rates the YS81-CS at 1,480 psi WOG non-shock at 100°F.
What material is the body?
The body is ASTM A216 Grade WCB carbon steel with an epoxy-painted exterior.
What screen material does Titan use for stocked configurations?
Titan identifies Type 304 stainless steel for stocked mesh and perforation selections.
What sizes are available?
The YS81-CS is available from 1/4" through 2".
Important Ordering Notes
- Select the required nominal pipe size before adding the product to your cart.
- The selected variation determines the Titan part code, price, shipping weight, and net cost.
- Confirm required mesh or perforation before ordering when the standard configuration does not suit the application.
- Confirm pressure, temperature, media compatibility, thread requirements, and applicable code requirements before installation.
- Review Titan's current specification sheet and IOM manual before installation or maintenance.
