Titan Flow Control
Carbon Steel Flanged Y Strainer - Class 300
- SKU:
- YS62-CS
- Availability:
- Usually in Stock – Ships Quickly
- Weight:
- 0.00 LBS
Description
Titan Carbon Steel Flanged Y Strainer - Class 300
Titan Flow Control YS62-CS carbon steel flanged Y strainers provide heavy-duty debris removal for higher-pressure industrial piping systems while helping protect pumps, meters, control valves, spray nozzles, compressors, turbines, and other downstream equipment.
Select the required nominal size from the product options. Confirm the published rating for the selected configuration and service.
Product Highlights
- Carbon Steel - ASTM A216 Grade WCB.
- Flanged - Raised Face connections.
- ASME Class 300 design.
- Inlet and outlet gauge taps on applicable sizes.
- Large straining capacity with precision-machined screen seats.
- Self-cleaning capability with an appropriate blow-off arrangement.
- Epoxy-painted exterior; optional cover designs available from Titan.
Product Specifications
| Manufacturer | Titan Flow Control |
|---|---|
| Model | YS62-CS |
| Body Material | Carbon Steel - ASTM A216 Grade WCB |
| Configuration | Y / Wye Strainer |
| Connections | Flanged - Raised Face |
| Pressure Class | ASME Class 300 |
| Pressure Rating | 740 psi WOG non-shock at 100°F |
| Body Finish | Epoxy Painted |
| Stocked Screen / Perforation Material | Type 304 Stainless Steel |
| Stocked Mesh Options | 10, 20, 30, 40, 60, 80, and 100 Mesh |
| Stocked Perforation Options | 1/32", 3/64", 1/16", 1/8", 5/32", and 1/4" |
| Titan Published Size Range | 1/2" through 16" |
| GetPipe Variants on This Listing | 1/2" through 12" |
How a Class 300 Y Strainer Works
Process flow passes through the internal cylindrical straining element, where debris is captured before it can reach downstream equipment. The Y-shaped body provides a collection area for solids and access to the straining element for routine inspection and cleaning. Titan equips this series with inlet and outlet gauge taps on applicable sizes so differential pressure can be monitored as the straining element loads. A tapped blow-off connection can also be fitted with a blow-down valve to assist with cleaning.
Screen & Perforation Selection
Titan stocks multiple Type 304 stainless steel mesh and perforation selections for the YS62-CS. Choose the straining element based on particle size, allowable pressure drop, flow requirements, and service conditions. Contact GetPipe.com when a specific mesh or perforation is required so the correct configuration can be confirmed before ordering.
Common Applications
Compatible high-pressure process-water, oil, and petrochemical service. Helps protect pumps, meters, control valves, spray nozzles, compressors, and turbines.
Selection & Ordering Notes
Select the required nominal pipe size before adding the product to your cart.
Confirm mating flange dimensions, pressure class, gasket and bolting requirements before installation.
Confirm required mesh or perforation before ordering when the standard configuration does not suit the application.
Sizes over GetPipe parcel-weight limits ship by freight; freight charges apply according to GetPipe shipping policy.
Confirm pressure, temperature, media compatibility, installation orientation, and applicable code requirements before use.
Request the current Titan specification sheet or certified drawing when exact installation dimensions are required.
Product Questions
What is the Titan YS62-CS?
It is an ASTM A216 Grade WCB carbon steel, raised-face flanged Y strainer with an ASME Class 300 rating.
What is the pressure rating?
Titan rates the YS62-CS at 740 psi WOG non-shock at 100°F.
What screen options are available?
Titan stocks Type 304 stainless steel mesh selections from 10 through 100 mesh and multiple perforation sizes from 1/32" through 1/4".
Why are gauge taps provided?
Gauge taps allow inlet and outlet pressure to be monitored so differential pressure across the straining element can be evaluated as debris accumulates.
Does Titan manufacture the YS62-CS larger than 12"?
Yes. Titan publishes the YS62-CS through 16". This GetPipe listing currently includes sizes through 12" because those are the sizes supported by the current GetPipe/Titan consolidated net-cost data.
