PVC DWV Long Sweep 1/4 Bend 90, Street (HUB x SPG)
- SKU:
- LP309
- Availability:
- Usually Ships Same Day
- Weight:
- 0.00 LBS
Description
PVC DWV Long Sweep 1/4 Bend 90° Street Elbow (HUB x SPG)
PVC DWV Long Sweep 1/4 Bend 90° Street Elbows provide a smooth, space-efficient 90-degree directional change in non-pressurized drain, waste, and vent piping systems.
Featuring a hub connection on one end and a spigot (SPG) connection on the other, this street elbow can accept compatible PVC DWV pipe while also fitting directly into another hub fitting. The long sweep radius creates a more gradual flow path, while the street-style configuration helps reduce the need for additional couplings in residential, commercial, and industrial DWV installations.
Product Highlights
- PVC DWV long sweep 1/4 bend 90° street elbow
- Hub x Spigot (SPG) connection configuration
- Provides a gradual 90° directional change
- Long sweep radius supports efficient gravity flow
- Street-style design helps reduce additional fittings
- Hub end accepts compatible PVC DWV pipe
- Spigot end fits directly into a compatible hub fitting
- Designed for non-pressurized drain, waste, and vent systems
- Solvent-weld installation
- Durable corrosion-resistant PVC construction
- Suitable for residential, commercial, and industrial DWV systems
Technical Specifications
| Product Type | DWV Long Sweep Street 1/4 Bend Elbow |
|---|---|
| Material | PVC |
| Bend Angle | 90° |
| Connection Type | Hub x Spigot (SPG) |
| Bend Style | Long Sweep |
| Joint Method | Solvent Weld |
| System Type | Drain, Waste & Vent (DWV) |
| Pressure Service | Non-Pressure |
| Primary Function | Gradual 90° Directional Change |
| Typical Applications | Residential, Commercial, and Industrial DWV Systems |
Connection Configuration
Hub End
The hub connection accepts compatible PVC DWV pipe for a permanent solvent-weld joint.
Long Sweep Bend
The extended-radius body creates a gradual 90-degree transition that supports smoother gravity drainage through the fitting.
Spigot End
The SPG end is designed to fit directly into a compatible PVC hub fitting, helping minimize the need for an additional coupling.
Construction Details
The elbow is manufactured from durable PVC for corrosion resistance and dependable long-term service in compatible non-pressure drain, waste, and vent systems.
The long sweep radius creates a more gradual flow path than a standard short-radius elbow, helping reduce abrupt directional changes and unnecessary turbulence.
The combination of a hub end and spigot end allows the fitting to connect directly into another hub while accepting PVC DWV pipe on the opposite side.
Why Choose a Long Sweep Street 90° Elbow?
Smoother Flow Path
- Gradual 90° directional change
- Longer-radius bend than a standard elbow
- Helps reduce turbulence
- Supports efficient gravity drainage
- Can help reduce areas where debris may accumulate
Compact Street Configuration
- Spigot end fits directly into a hub
- Helps reduce additional couplings
- Useful where installation space is limited
- Simplifies some fitting-to-fitting connections
- Suitable for new installations and repairs
Typical Applications
Residential DWV Systems
- Building drains
- Waste piping
- Fixture drainage systems
- Horizontal drainage runs
- Compact DWV layouts
Commercial & Industrial DWV
- Commercial drainage systems
- Building waste piping
- Vent system transitions
- Repair and retrofit work
- Compatible gravity-flow DWV systems
Solvent-Weld Installation
Clean and prepare the mating PVC surfaces according to accepted solvent-weld procedures. Apply compatible PVC primer and solvent cement where required.
Fully seat compatible PVC DWV pipe into the hub end and insert the spigot end into the mating hub fitting. Confirm the required 90-degree orientation before the solvent cement begins to set.
Allow all completed joints to cure according to the solvent-cement manufacturer's recommendations before placing the system into normal service.
Our plumbing specialists can help review your pipe size, hub and spigot connections, DWV layout, and solvent-weld requirements before you order.
Email the GetPipe.com Team Visit Quick SupportFrequently Asked Questions
What is a PVC DWV long sweep street 90° elbow?
It is a 90-degree elbow with an extended sweep radius and a hub on one end with a spigot on the other.
What does HUB mean?
Hub refers to the socket connection that accepts compatible PVC DWV pipe for solvent-weld installation.
What does SPG mean?
SPG means spigot. The spigot end fits directly into a compatible hub fitting.
What is the advantage of the long sweep design?
The longer-radius bend provides a smoother directional change that can reduce turbulence and support efficient gravity drainage.
How is a street elbow different from a standard long sweep elbow?
A standard long sweep elbow typically has hubs on both ends, while a street version has a hub on one end and a spigot on the other.
Why use a street-style fitting?
The spigot end can connect directly into another hub fitting, helping reduce the need for an additional coupling or intermediate pipe section.
How is this fitting installed?
Both the hub and spigot connections are installed using compatible PVC solvent-weld procedures.
Is this fitting intended for pressure piping?
No. This elbow is intended for non-pressurized drain, waste, and vent applications.
What material is the fitting made from?
The elbow is manufactured from durable, corrosion-resistant PVC.
What should I verify before ordering?
Confirm the nominal size, Hub x Spigot configuration, long sweep requirement, and compatibility with the intended PVC DWV system.
Important Ordering & Installation Notes
- This listing is for a PVC DWV Long Sweep 1/4 Bend 90° Street Elbow with HUB x SPG connections.
- Verify the required nominal size before ordering.
- The fitting provides a gradual 90-degree directional change.
- The hub end accepts compatible PVC DWV pipe.
- The spigot end fits directly into a compatible hub fitting.
- The street configuration may reduce the need for additional couplings.
- The long sweep radius provides a smoother flow path than a standard short-radius elbow.
- Designed for non-pressurized drain, waste, and vent systems.
- Use compatible PVC primer and solvent cement where required.
- Clean and prepare all mating surfaces before solvent welding.
- Fully seat both connections during assembly.
- Confirm fitting orientation before the solvent cement begins to set.
- Allow completed joints to cure according to the cement manufacturer's recommendations.
- Do not use this fitting for pressure applications.
- Follow applicable plumbing codes and installation requirements.
