Dixon

2-1/2" Aluminum Type D Cam & Groove Coupler x Female NPT

(No reviews yet) Write a Review
SKU:
NLDIX250-D-AL
Availability:
Limited quantity available.
Weight:
1.50 LBS
*Images are for visual reference only.
  • 2-1/2" Aluminum Type D Cam & Groove Coupler x Female NPT
  • Dixon Logo
$44.00

Represents the combined quantity sold of all the sizes under this product SKU.
Sold:
Frequently bought together:

Description

Dixon 2-1/2" Aluminum Type D Cam & Groove Coupler x Female NPT

The Dixon 2-1/2" Aluminum Type D Cam & Groove Coupler is designed for reliable fluid transfer connections in industrial, agricultural, construction, and petroleum handling systems.

This Type D fitting combines a female cam and groove coupler with a female NPT threaded connection for secure integration with compatible hose and pipe systems. Manufactured from durable 356T6 aluminum and equipped with a Buna-N nitrile gasket and stainless steel cam arm pins, the coupler provides corrosion resistance, dependable sealing, and quick-connect convenience for compatible liquid transfer applications.

Product Highlights

  • 2-1/2" Type D cam and groove coupler
  • Female camlock coupler x female NPT thread
  • Durable 356T6 aluminum construction
  • Maximum working pressure: 150 PSI at 70°F
  • Buna-N nitrile gasket included
  • Precision machined for reliable fit and sealing
  • Stainless steel cam arm pins
  • Lightweight, corrosion-resistant aluminum body
  • Interchanges with standard commercial cam and groove fittings
  • Made to Commercial Item Description A-A-59326D standards
  • Designed for compatible liquid transfer applications

Technical Specifications

Brand Dixon
Product Type Cam & Groove Coupler x Female NPT
Fitting Type Type D
Nominal Size 2-1/2"
Connection 1 Female Cam & Groove Coupler
Connection 2 Female NPT Thread
Body Material 356T6 Aluminum
Gasket Material Buna-N Nitrile Rubber
Cam Arm Pins Stainless Steel
Construction Precision Machined
Maximum Working Pressure 150 PSI at 70°F
Interchange Standard Commercial Cam & Groove Fittings
Standard Commercial Item Description A-A-59326D
Intended Service Liquid Transfer

Type D Connection Configuration

Female Cam & Groove Coupler

One end features a 2-1/2" female cam and groove coupler designed to connect with a compatible male cam and groove adapter.

Female NPT Connection

The opposite end features a female NPT threaded connection for attachment to a compatible male threaded hose or pipe system component.

356T6 Aluminum Construction

The Type D coupler is manufactured from 356T6 aluminum, providing a durable, lightweight, and corrosion-resistant fitting for compatible liquid transfer environments.

Buna-N Nitrile Gasket

An included Buna-N nitrile gasket provides the sealing surface within the female cam and groove coupler, helping create a leak-resistant connection with compatible male adapters.

Always verify chemical compatibility of the gasket and aluminum body with the specific fluid being transferred.

Stainless Steel Cam Arm Pins

The cam arms are equipped with stainless steel pins for added durability and resistance to rust or binding during repeated connection and disconnection.

Precision-Machined Construction

The aluminum body is precision machined to help provide a reliable fit and sealing interface with compatible cam and groove adapters.

Maximum Working Pressure

150 PSI at 70°F

The supplied product information lists a maximum working pressure of 150 PSI at 70°F. Verify the pressure rating of the complete system and all connected components for the actual operating conditions before use.

A-A-59326D Standard & Interchange

This Type D coupler is made to Commercial Item Description A-A-59326D standards and is designed to interchange with compatible standard commercial cam and groove fittings.

Typical Applications

  • Industrial liquid transfer systems
  • Agricultural fluid handling
  • Construction fluid transfer systems
  • Compatible petroleum handling systems
  • Hose and pipe connection systems
  • Compatible commercial cam and groove systems

Installation & Service Notes

This Type D coupler is rated for liquid transfer service up to 150 PSI at 70°F. Always verify chemical compatibility, system pressure rating, and connection requirements before installation.

Willy knows his Dixon Type D aluminum cam and groove couplers
Ask Willy: Need Help with a 2-1/2" Type D Camlock Coupler?

Our specialists can help with Type D fitting selection, cam and groove compatibility, female NPT connections, gasket compatibility, and pressure requirements for your liquid transfer system.

Email the GetPipe.com Team Visit Quick Support

Frequently Asked Questions

What is a Type D cam and groove coupler?

A Type D fitting combines a female cam and groove coupler with a female NPT threaded connection.

What size is this Type D coupler?

The supplied product information identifies this fitting as a 2-1/2" Type D cam and groove coupler.

What material is the coupler body made from?

The body is manufactured from 356T6 aluminum.

What gasket material is included?

The coupler includes a Buna-N nitrile gasket for sealing with a compatible male cam and groove adapter.

What is the maximum working pressure?

The supplied product information lists a maximum working pressure of 150 PSI at 70°F.

What material are the cam arm pins?

The cam arm pins are stainless steel, providing durability and resistance to rust or binding during repeated use.

What does the female camlock end connect to?

The female cam and groove coupler is designed to connect with a compatible male cam and groove adapter.

What does the female NPT end connect to?

The female NPT connection is designed for attachment to a compatible male NPT threaded connection.

Does this coupler interchange with standard cam and groove fittings?

Yes. The supplied product information states that the fitting interchanges with compatible standard commercial cam and groove fittings.

What standard is this Type D coupler made to?

The supplied product information states that the coupler is made to Commercial Item Description A-A-59326D standards.

Important Ordering & Product Notes

  • This listing covers a Dixon 2-1/2" Aluminum Type D Cam & Groove Coupler x Female NPT.
  • Fitting type is Type D.
  • Nominal size is 2-1/2".
  • Connection configuration is female cam & groove coupler x female NPT.
  • Body material is 356T6 aluminum.
  • An included Buna-N nitrile gasket provides the cam and groove sealing surface.
  • Cam arm pins are stainless steel.
  • Maximum working pressure is listed as 150 PSI at 70°F.
  • Made to Commercial Item Description A-A-59326D standards.
  • Designed to interchange with compatible standard commercial cam and groove fittings.
  • The specific female NPT thread designation and manufacturer part number were not supplied in the provided product information.
  • Verify chemical compatibility, pressure rating, and connection requirements before installation.
