Dixon

1-1/2" Type D Cam & Groove Coupler x Female NPT Aluminum Fitting

(No reviews yet) Write a Review
SKU:
NLDIX150-D-AL
Availability:
Limited quantity available.
Weight:
1.00 LBS
*Images are for visual reference only.
  • 1-1/2" Type D Cam & Groove Coupler x Female NPT Aluminum Fitting
  • Dixon Logo
$26.00

Represents the combined quantity sold of all the sizes under this product SKU.
Sold:
Frequently bought together:

Description

Dixon 150-D-AL 1-1/2" Type D Cam & Groove Coupler x Female NPT Aluminum Fitting

The Dixon 150-D-AL 1-1/2" Type D Cam & Groove Coupler is designed for quick and secure connections in compatible liquid transfer systems.

Constructed from durable 356T6 aluminum, this straight fitting combines a 1-1/2" female cam & groove coupler with a female NPT threaded connection. Precision-machined construction, a Buna-N nitrile rubber seal, and stainless steel pins support dependable sealing, connection, and durability for industrial, agricultural, petroleum, chemical, and general hose applications.

Product Highlights

  • Dixon 1-1/2" Type D cam and groove coupler
  • Manufacturer part number: 150-D-AL
  • Female cam & groove coupler x female NPT connection
  • 356T6 aluminum construction
  • Buna-N nitrile rubber seal
  • Maximum operating pressure: 250 PSI
  • Straight fitting configuration
  • Precision machined to rigid tolerances
  • Stainless steel pins for strength and durability
  • Lightweight, corrosion-resistant aluminum body
  • Quick connection and disconnection with compatible male camlock adapters
  • Package quantity: 1 each
  • Not for compressed air or steam service

Technical Specifications

Brand Dixon Valve & Coupling
Manufacturer Part Number 150-D-AL
Alternate SKUs 150DAL, DIX150-D-AL, NLDIX150-D-AL
Product Type Cam & Groove Coupler
Fitting Type Type D
Nominal Size 1-1/2"
Connection 1 Female Cam & Groove Coupler
Connection 2 Female NPT
Material 356T6 Aluminum
Seal Material Nitrile Rubber / Buna-N
Pin Material Stainless Steel
Maximum Operating Pressure 250 PSI
Fitting Shape Straight
Package Quantity 1 Each
Service Restriction Not for Compressed Air or Steam Service

Type D Connection Configuration

Female Cam & Groove Coupler

The coupling end features a 1-1/2" female cam & groove connection designed for quick connection and disconnection with a compatible male camlock adapter.

Female NPT Connection

The opposite end features a female NPT threaded connection for attachment to compatible threaded pipe, equipment, valves, or other fluid transfer components.

356T6 Aluminum Construction

The Dixon 150-D-AL is manufactured from 356T6 aluminum. The aluminum body provides a lightweight, corrosion-resistant fitting option for compatible cam and groove hose and liquid transfer systems.

Buna-N Nitrile Rubber Seal

The coupler uses a Buna-N nitrile rubber seal to support dependable sealing when connected to a compatible male cam and groove adapter. Verify chemical and media compatibility before installation.

Stainless Steel Pins

The 150-D-AL incorporates stainless steel pins for strength and durability as part of the camlock coupling assembly.

Precision-Machined Design

The fitting is precision machined to rigid tolerances to support reliable fit, sealing, and performance with compatible cam and groove components.

Straight Fitting Configuration

The 150-D-AL uses a straight fitting configuration, providing an in-line transition from a female cam and groove coupler connection to a female NPT threaded connection.

Maximum Operating Pressure

250 PSI Maximum

The supplied product information lists a maximum operating pressure of 250 PSI. Verify the pressure ratings of all connected hoses, piping, valves, equipment, and other system components before operation.

Typical Applications

  • Industrial liquid transfer
  • Agricultural fluid handling
  • Petroleum applications
  • Chemical applications
  • General hose applications
  • Compatible cam and groove hose assemblies

Service Restrictions

Under no circumstances should cam and groove couplings be used for compressed air or steam service. Verify chemical compatibility, pressure rating, and connection size before installation.

Willy knows his Dixon Type D aluminum cam and groove couplers
Ask Willy: Have a Question About the Dixon 150-D-AL?

Our specialists can help with camlock compatibility, female NPT connections, seal selection, pressure requirements, chemical compatibility, and application questions for the Dixon 150-D-AL 1-1/2" Type D Aluminum Cam & Groove Coupler.

Email the GetPipe.com Team Visit Quick Support

Frequently Asked Questions

What is the Dixon 150-D-AL?

The 150-D-AL is a 1-1/2" Type D aluminum cam and groove coupler featuring a female camlock connection on one end and a female NPT threaded connection on the other.

What connections does the 150-D-AL have?

The fitting has a female cam & groove coupler connection and a female NPT threaded connection.

What material is the 150-D-AL made from?

The fitting is manufactured from 356T6 aluminum.

What seal material does the 150-D-AL use?

The supplied product information identifies a Buna-N nitrile rubber seal.

What material are the coupling pins?

The supplied product information identifies stainless steel pins.

What is the maximum operating pressure?

The supplied product information lists a maximum operating pressure of 250 PSI.

Is the 150-D-AL a straight fitting?

Yes. The supplied product information identifies the 150-D-AL as a straight fitting.

What applications are identified for the 150-D-AL?

The supplied product information identifies industrial, agricultural, petroleum, chemical, and general hose applications for compatible liquid transfer systems.

How many couplers are included?

The supplied product information lists a package quantity of 1 each.

Can the 150-D-AL be used for compressed air or steam?

No. The supplied product information states that cam and groove couplings should not be used for compressed air or steam service.

Important Ordering & Product Notes

  • This listing covers the Dixon 150-D-AL 1-1/2" Type D Cam & Groove Coupler x Female NPT Aluminum Fitting.
  • Manufacturer part number: 150-D-AL.
  • Alternate SKUs: 150DAL, DIX150-D-AL, NLDIX150-D-AL.
  • Nominal size is 1-1/2".
  • Connection configuration is female cam & groove coupler x female NPT.
  • Construction material is 356T6 aluminum.
  • Seal material is Buna-N nitrile rubber.
  • Coupling pins are stainless steel.
  • Maximum operating pressure is listed as 250 PSI.
  • Fitting configuration is straight.
  • Package quantity is 1 each.
  • Verify chemical compatibility, pressure rating, and connection size before installation.
  • Do not use cam and groove couplings for compressed air or steam service.
