4" Aluminum Cam & Groove Type D Coupler x Female NPT

(No reviews yet) Write a Review
SKU:
NLDIX400-D-AL
Availability:
Limited quantity available.
Weight:
2.70 LBS
*Images are for visual reference only.
  • 4" Aluminum Cam & Groove Type D Coupler x Female NPT
  • Dixon Logo
$60.00

Represents the combined quantity sold of all the sizes under this product SKU.
Sold:
Frequently bought together:

Description

4" Aluminum Cam & Groove Type D Coupler x Female NPT

4" Aluminum Cam & Groove Type D Coupler x Female NPT combines a female cam and groove coupler with a female threaded connection for compatible liquid-transfer systems.

Constructed from 356T6 aluminum, the Dixon 400-D-AL uses a nitrile rubber gasket and stainless steel cam-arm pins. The 4" fitting is rated to a maximum operating pressure of 100 PSI.

PRODUCT OVERVIEW

Product Highlights

356T6 aluminum Type D coupler designed to connect compatible 4" cam and groove and threaded equipment.

The 400-D-AL combines a female cam and groove coupler with a 4" female NPT connection for liquid service.

356T6 Aluminum Construction
4" Nominal Size
Type D Coupler Style
Female Coupler Cam & Groove Side
Female NPT Threaded Side
100 PSI Maximum Pressure

Technical Specifications

Product Type Type D Coupler
Manufacturer Dixon
Part Number 400-D-AL
Material 356T6 Aluminum
Nominal Size 4"
Configuration Coupler x Female NPT
Thread Size 4" Female NPT
Seal Material Nitrile Rubber
Maximum Pressure 100 PSI
Specification A-A-59326D

Type D Connection Configuration

CAM & GROOVE SIDE
4" Female Coupler

The female cam and groove end accepts a compatible 4" male adapter and secures the connection when both cam arms are properly engaged.

+
THREADED SIDE
4" Female NPT Connection

The opposite end provides a 4" female NPT thread for connection to compatible male-threaded pipe, fittings, or equipment.

Type D Aluminum Cam & Groove Coupler Design

01
4" Type D Connection Configuration

The Dixon 400-D-AL combines a 4" female cam and groove coupler with a 4" female NPT connection. This Type D arrangement provides a transition between compatible male cam and groove adapters and male-threaded piping or equipment.

The cam and groove side allows repeated connection and disconnection without rotating the mating adapter. Confirm both the 4" nominal cam and groove size and the 4" female NPT thread requirement before installing the fitting.

02
356T6 Aluminum Construction

Dixon manufactures the 400-D-AL from 356T6 aluminum for compatible liquid-transfer applications. The aluminum body provides a durable connection while remaining practical for systems where couplings may be connected and disconnected regularly.

The coupler also uses durable stainless steel cam-arm pins designed to resist rusting or binding during operation. Inspect the body, cam arms, pins, threads, and mating components regularly for damage, contamination, or excessive wear.

03
Female Cam & Groove Coupler

The female coupler accepts a compatible male cam and groove adapter, with the connection secured by pressing both cam levers down using normal hand pressure. Lifting the cam arms releases the adapter when the assembly is ready to be disconnected.

A nitrile rubber gasket is supplied as the standard seal and is retained within the coupler recess for proper placement. Inspect the gasket before use and confirm its compatibility with the transferred liquid and operating conditions.

04
Female NPT Threaded Connection

The threaded side of the 400-D-AL provides a 4" female NPT connection for attachment to compatible male-threaded components. Dixon's dimensional drawing confirms the 4" female NPT thread used on this specific part number.

Dixon rates the fitting to a maximum operating pressure of 100 PSI under its stated conditions. The coupling is designed for liquid service and must not be used for compressed air or steam applications.

Installation & Selection Considerations

01

Confirm the 4" nominal size.

02

Verify the Type D configuration.

03

Inspect the nitrile gasket.

04

Confirm the 4" female NPT thread.

05

Verify liquid compatibility.

Willy knows his pipe sizes
Ask Willy: Need Help Selecting a Type D Cam & Groove Coupler?

Our product specialists can help review nominal size, aluminum construction, Type D configuration, gasket compatibility, female NPT connection, and intended liquid service before you order.

Frequently Asked Questions

What is the Dixon 400-D-AL?

The 400-D-AL is a 4" Type D aluminum cam and groove coupler with a female coupler connection and a 4" female NPT threaded connection.

What material is the 400-D-AL made from?

Dixon manufactures the 400-D-AL from 356T6 aluminum and uses stainless steel cam-arm pins.

What gasket is supplied with the coupler?

The 400-D-AL is supplied with a nitrile rubber gasket. Dixon also offers other gasket materials for applications requiring different compatibility.

What is the threaded connection size?

The threaded side of the 400-D-AL is a 4" female NPT connection.

What is the maximum operating pressure?

Dixon lists a maximum operating pressure of 100 PSI for the 400-D-AL under its stated operating conditions.

Can the 400-D-AL be used for compressed air or steam?

No. Dixon states that cam and groove couplings must not be used for compressed air or steam service.

Important Ordering & Installation Notes

  • Verify Dixon part number 400-D-AL.
  • Confirm the 4" nominal size.
  • Verify the Type D configuration.
  • Confirm 356T6 aluminum construction.
  • Confirm the 4" female NPT connection.
  • Inspect the nitrile gasket before use.
  • Check both cam arms for proper engagement.
  • Confirm liquid and material compatibility.
  • Do not use for compressed air or steam.
  • Observe the 100 PSI maximum pressure rating.
