1" Aluminum Camlock Type D Coupler x Female NPT
- SKU:
- NLDIX100-D-AL
- Availability:
- Limited quantity available.
- Weight:
- 0.50 LBS
Description
Dixon 100-D-AL 1" Aluminum Camlock Type D Coupler x Female NPT
The Dixon 100-D-AL 1" Type D Cam & Groove Coupler is designed with a female camlock connection and female NPT threaded end for quick, secure connections in compatible liquid transfer systems.
Manufactured from 356T6 aluminum, the 100-D-AL combines lightweight construction with corrosion resistance and strength. Stainless steel cam arm pins and a Buna-N nitrile rubber gasket support dependable coupling and sealing performance in industrial, agricultural, petroleum, and general fluid handling applications.
Product Highlights
- Dixon Type D cam and groove coupler
- Model: 100-D-AL
- 1" coupling size
- Female camlock coupler x female NPT thread
- 356T6 aluminum construction
- Buna-N nitrile rubber gasket
- Maximum operating pressure: 250 PSI
- Stainless steel cam arm pins
- Precision-machined construction
- Interchangeable with standard cam and groove fittings
- Built to A-A-59326D specifications
- Designed for liquid transfer applications
- Not recommended for compressed air or steam service
Technical Specifications
| Brand | Dixon |
|---|---|
| Model | 100-D-AL |
| Product Type | Type D Cam & Groove Coupler |
| Size | 1" |
| Connection 1 | Female Camlock Coupler |
| Connection 2 | Female NPT Thread |
| Material | 356T6 Aluminum |
| Gasket Material | Buna-N / Nitrile Rubber |
| Cam Arm Pins | Stainless Steel |
| Maximum Operating Pressure | 250 PSI |
| Specification | A-A-59326D |
| Intended Service | Liquid Transfer Applications |
| Service Restriction | Not Recommended for Compressed Air or Steam |
Type D Connection Configuration
Female Camlock Coupler
The cam and groove side features a 1" female camlock coupler for quick connection and disconnection with compatible cam and groove adapters.
Female NPT Thread
The opposite end features a female NPT threaded connection for connection to compatible threaded pipe, fittings, and fluid transfer equipment.
356T6 Aluminum Construction
The 100-D-AL is manufactured from 356T6 aluminum, providing corrosion resistance and strength while maintaining a lightweight configuration for handling and installation.
Cam Arms & Sealing
Stainless Steel Cam Arm Pins
The supplied product information identifies stainless steel cam arm pins as part of the coupling construction.
Buna-N Gasket
A Buna-N nitrile rubber gasket provides sealing within compatible cam and groove connections. Verify gasket and fluid compatibility before use.
Maximum Operating Pressure
250 PSI Maximum
The supplied product information lists a maximum operating pressure of 250 PSI. The allowable pressure of a complete transfer system should also account for the ratings of connected hose, piping, fittings, and other components.
A-A-59326D Specification
The supplied product information identifies the Dixon 100-D-AL as being built to A-A-59326D specifications and interchangeable with standard cam and groove fittings.
Typical Applications
- Industrial liquid transfer
- Agricultural fluid handling
- Petroleum transfer applications
- General fluid handling systems
- Cam and groove transfer assemblies
- Threaded piping and fitting connections
Service Restrictions
The 100-D-AL is intended for liquid transfer applications. The supplied product information states that this coupling is not recommended for compressed air or steam service.
Our specialists can help with connection, gasket, pressure, and application questions for the Dixon 100-D-AL 1" Aluminum Type D Cam & Groove Coupler.
Email the GetPipe.com Team Visit Quick SupportFrequently Asked Questions
What is the Dixon 100-D-AL?
The 100-D-AL is a 1" aluminum Type D cam and groove coupler featuring a female camlock connection and female NPT threaded end.
What connections does a Type D coupling have?
The supplied 100-D-AL configuration has a female camlock coupler on one end and a female NPT thread on the other.
What material is the 100-D-AL made from?
The supplied product information identifies 356T6 aluminum construction.
What gasket does the 100-D-AL use?
The supplied configuration includes a Buna-N nitrile rubber gasket.
What are the cam arm pins made from?
The supplied product information identifies stainless steel cam arm pins.
What is the maximum operating pressure?
The supplied product information lists a maximum operating pressure of 250 PSI.
Does the 100-D-AL interchange with standard cam and groove fittings?
Yes. The supplied product information identifies the coupling as interchangeable with standard cam and groove fittings.
What specification is the 100-D-AL built to?
The supplied product information identifies A-A-59326D specifications.
Can the 100-D-AL be used for compressed air?
No. The supplied product information states that the coupling is not recommended for compressed air service.
Can the 100-D-AL be used for steam?
No. The supplied product information states that the coupling is not recommended for steam service.
Important Ordering & Product Notes
- This listing covers the Dixon 100-D-AL 1" Aluminum Type D Cam & Groove Coupler x Female NPT.
- Connection configuration is 1" female camlock coupler x female NPT thread.
- Construction material is listed as 356T6 aluminum.
- The supplied configuration includes a Buna-N nitrile rubber gasket.
- Cam arm pins are identified as stainless steel.
- Maximum operating pressure is listed as 250 PSI.
- The supplied product information identifies construction to A-A-59326D specifications.
- The coupling is identified as interchangeable with standard cam and groove fittings.
- Not recommended for compressed air or steam service.
- Verify chemical compatibility, gasket compatibility, operating pressure, connection requirements, and system component ratings before installation or use.
