Milwaukee
Milwaukee Tool 18" SDS+ CORE BIT ADAPTER
- SKU:
- MLW48-20-3593
- Availability:
- Usually Ships Same Day
- Weight:
- 0.72 LBS
Description
DUTY®
SDS-Plus Core Bit
Adapter
Use this 18 in adapter with the matching SDS-Plus masonry core system for larger brick, block and concrete openings.
Product Overview
The 18-inch SDS-Plus adapter connects compatible 1-3/16–4-3/8-inch masonry cores.
Its threaded mount lets you change the separate core body within the matching system.
- SDS-Plus fittingConnects to a rotary hammer.
- Threaded core mountAllows core-body changes.
- Two-piece systemFor matched masonry cores.
- Starting alignmentUses the matching pilot bit.
Technical Specifications
- Adapter length
- 18 in
- Hammer interface
- SDS-Plus
- Core connection
- Threaded
- Core system
- Two-piece masonry
- Core size range
- 1-3/16–4-3/8 in
- Centering bit
- 48-20-3580
Choose the Correct Fit
Match the adapter to the specified SDS-Plus masonry core system. Check the exact core-body part number and the hammer’s diameter capacity.
Allow room for the 18 in adapter and the complete tool setup. Check the core body’s usable depth separately from adapter length.
Installation & Care
Isolate the hammer before fitting the adapter, core body or centering bit. Check each connection and follow the starting procedure for the assembly.
Clean debris from the threads after use. Inspect the adapter and centering-bit attachment, and replace damaged parts before the next hole.
Small Details. Big Jobsite Energy.
Get set. Stay focused. Make your next move count.
THE NEXT JOB.
Ask Willy:
Need help completing a masonry core setup? Send Willy the core-body part number, hammer model and working reach required.
Important Product Questions
Does this fit every SDS-Plus core body?
SDS-Plus identifies the hammer connection, not every core-body thread. Confirm that the core body belongs to the matching two-piece masonry core system.
Does the adapter length equal the cutting depth?
No. 18 in identifies this adapter. The matching core bodies have their own usable depth and require core removal for deeper holes.
Which centering bit matches these adapters?
Milwaukee lists centering bit 48-20-3580 for adapters 48-20-3582 and 48-20-3593. Check the pilot and its mounting parts when assembling the setup.
