Harris
Harris ER80S-D2 Low-Alloy TIG Welding Rod
- Availability:
- Usually in Stock – Ships Quickly
- Weight:
- 0.00 LBS
Description
Harris ER80S-D2 Low-Alloy TIG Welding Rod
Harris ER80S-D2 TIG (GTAW) welding rod is a low-alloy filler metal containing molybdenum for increased strength, with manganese and silicon deoxidizers to help produce high-quality weld deposits on carbon and low-alloy steels.
Select the required rod diameter from the product options above. Each variation is supplied in 36-inch cut lengths in a 10 lb box and determines the Harris part number, online selling price, shipping weight, and net cost.
Product Highlights
- ER80S-D2 low-alloy TIG / GTAW filler rod
- Contains molybdenum for increased weld-metal strength
- Manganese and silicon deoxidizers support sound weld deposits
- Designed for carbon and low-alloy steels
- Suitable for single- and multi-pass welding
- 36 in. cut-length TIG rods
- Available in 1/16 in., 3/32 in., and 1/8 in. diameters
- Conforms to AWS A5.28 ER80S-D2
Technical Specifications
Common Applications
Fabrication
- Carbon-steel fabrication
- Low-alloy steel fabrication
- Single-pass welding
- Multi-pass welding
Industrial & Repair
- General industrial fabrication
- Equipment repair
- Maintenance welding
- Low-alloy steel components
Product Resources
Review current Harris manufacturer information and the applicable welding procedure before final product selection or welding.
Need Help Selecting ER80S-D2 TIG Rod?
Our GetPipe.com team can help confirm rod diameter, base material, filler-metal classification, welding requirements, product availability, and related welding supplies.
Frequently Asked Questions
What is Harris ER80S-D2 TIG rod used for?
Harris ER80S-D2 is used for TIG welding carbon and low-alloy steels in single- and multi-pass fabrication and repair applications.
Why does ER80S-D2 contain molybdenum?
Molybdenum is included to increase strength in the deposited weld metal.
What diameters are available?
This GetPipe.com listing includes 1/16 in., 3/32 in., and 1/8 in. diameters.
What package size is supplied?
Each diameter is supplied as 36-inch TIG rod in a 10 lb box.
Does Harris ER80S-D2 meet AWS requirements?
Yes. Harris ER80S-D2 conforms to AWS A5.28 ER80S-D2.
Important Ordering & Safety Notes
- Select the correct rod diameter before adding the product to your cart.
- Each variation is supplied in a 10 lb box of 36-inch TIG rods.
- Selected variation determines the Harris part number, online price, shipping weight, and cost.
- Verify the qualified welding procedure, base material, shielding gas, preheat/interpass requirements, and applicable code requirements before use.
- Welding fumes and gases can be hazardous. Review current manufacturer labeling and safety documentation and follow applicable workplace safety requirements.
