ABS DWV 45 Reducing Double Wye (ALL HUB)
- SKU:
- LN612
- Availability:
- Usually Ships Same Day
- Weight:
- 0.00 LBS
Description
ABS DWV 45 Reducing Double Wye (ALL HUB)
ABS DWV 45 Reducing Double Wyes provide two opposing 45-degree branch connections while also transitioning between different nominal pipe sizes in non-pressure drain, waste, and vent systems.
Featuring hub connections on all openings, this fitting is designed to connect multiple compatible ABS DWV branch lines into a common main run while accommodating a pipe-size reduction. Each branch enters the main run at a gradual 45-degree angle, helping support smoother drainage flow and minimizing abrupt directional changes. The reducing configuration can also reduce the need for separate reducer fittings in certain layouts. Manufactured for ABS DWV service, it meets recognized standards including ASTM D2661, CSA B181.1, and NSF Standard 14.
Product Highlights
- ABS DWV 45 reducing double wye
- All-hub connection configuration
- Provides two opposing 45-degree branch connections
- Transitions between different nominal pipe sizes
- Connects multiple branch lines to a common DWV main run
- Gradual branch geometry supports smooth drainage flow
- Can reduce the need for separate wye fittings
- Can reduce the need for separate reducers
- Hub connections accept compatible ABS DWV pipe
- Designed for solvent-cement installation
- Suitable for drain, waste, and vent systems
- Suitable for sewer and general drainage applications
- Non-pressure fitting
- Maximum operating temperature of 140°F
- Not intended for compressed air or gas service
- Not intended for pressure testing
- Manufactured from virgin ABS polymers
- Complies with ASTM D2661
- Certified to CSA B181.1
- Meets NSF Standard 14 requirements
Technical Specifications
| Product Type | ABS DWV 45 Reducing Double Wye |
|---|---|
| Material | ABS |
| Connection Type | All Hub |
| Configuration | Reducing Double Wye |
| Branch Arrangement | Two Opposing 45-Degree Branches |
| Joint Method | Solvent Cement |
| System Type | Drain, Waste, and Vent (DWV) |
| Pressure Service | Non-Pressure |
| Maximum Operating Temperature | 140°F |
| Primary Function | Provide Two Opposing 45-Degree Branch Connections with a Pipe-Size Transition |
| Referenced Standards | ASTM D3965, ASTM D2661, CSA B181.1, NSF Standard 14 |
| Typical Applications | Sanitary Drainage, Waste Lines, Sewer Piping, General Drainage, and Reduced Multi-Branch DWV Connections |
Connection Configuration
Main Run Connections
The main hub connections form the primary ABS DWV piping path and accept compatible pipe for solvent-cement installation.
Opposing Reducing Branches
Two branch hubs enter the main run from opposite sides at approximately 45 degrees, with one or more connections reduced depending on the specific size configuration.
45 Reducing Double Wye Design
The 45 reducing double wye combines two opposing wye-style branches with a built-in size transition in one molded ABS fitting.
Each branch enters the main run at approximately 45 degrees, helping create a gradual directional change and efficient drainage path.
Because the fitting is reducing, one or more hub connections may differ in nominal size. Always verify the complete connection configuration before ordering.
Why Choose an ABS DWV 45 Reducing Double Wye?
Dual Branch & Size Transition
- Provides two opposing branch connections
- Each branch enters at approximately 45 degrees
- Transitions between different pipe sizes
- Supports smooth drainage flow
- Can consolidate multiple fittings into one assembly
ABS DWV Benefits
- Lightweight construction
- Easy handling and installation
- Suitable for non-pressure drainage systems
- Compatible with ABS DWV piping systems
- Designed for long-term sanitary drainage service
Typical Applications
Drainage Systems
- Sanitary drain lines
- Waste piping
- Sewer piping
- General building drainage
- ABS DWV main runs
Reducing Multi-Branch Layouts
- Opposing branch drains
- Different-size branch connections
- Multiple fixture branches
- Residential plumbing
- Commercial drainage systems
Standards & Compliance
- ASTM D3965: ABS material requirements for pipe extrusion and molded fittings
- ASTM D2661: Schedule 40 ABS drain, waste, and vent pipe and fittings
- CSA B181.1: ABS drain, waste, and vent pipe, fittings, and accessories
- NSF Standard 14: Plastic piping system components and related materials
Installation
Verify every nominal hub size before installation and identify which connection or connections provide the size reduction.
Cut all mating ABS pipe ends square and remove burrs. Clean and prepare the pipe and hub surfaces according to accepted ABS solvent-cement installation procedures.
Dry-fit the complete assembly before applying solvent cement to confirm main-run alignment, branch orientation, and proper placement of each pipe size.
Apply compatible ABS solvent cement as required and fully seat each pipe into its corresponding hub while maintaining correct alignment.
Allow completed joints to cure according to the solvent cement manufacturer's recommendations before placing the drainage system into service.
Our piping specialists can help review your main-run size, both branch sizes, reductions, fitting orientation, and ABS DWV compatibility before you order.
