Dixon
2-1/2" Type A Aluminum Male Cam x FNPT
- SKU:
- NLDIX250-A-AL
- Availability:
- Limited quantity available.
- Weight:
- 0.60 LBS
Description
Dixon 2-1/2" Type A Aluminum Male Cam x FNPT
The Dixon 2-1/2" Type A Cam & Groove Adapter is a durable aluminum camlock fitting designed for dependable liquid transfer connections in industrial and commercial hose systems.
Manufactured from 356T6 aluminum and precision machined to strict tolerances, this Type A adapter combines a male cam and groove connection with a 2-1/2"-8 female NPT threaded connection. Its lightweight, corrosion-resistant construction provides reliable performance while maintaining interchangeability with compatible cam and groove components manufactured to A-A-59326D specifications.
Product Highlights
- 2-1/2" Type A cam and groove adapter
- Male cam and groove adapter x female NPT thread
- 2-1/2"-8 FNPT thread size
- 356T6 aluminum construction
- Lightweight and corrosion-resistant design
- Precision machined for reliable fit and performance
- Interchanges with A-A-59326D compatible camlock fittings
- Maximum working pressure: 150 PSI
- Approximate length: 2-11/16"
- Hex size: 3-7/32"
- Designed for liquid transfer applications
- Not recommended for compressed air or steam service
Technical Specifications
| Brand | Dixon |
|---|---|
| Product Type | Cam & Groove Adapter |
| Fitting Type | Type A |
| Nominal Size | 2-1/2" |
| Connection 1 | Male Cam & Groove Adapter |
| Connection 2 | Female NPT |
| Thread Size | 2-1/2"-8 FNPT |
| Material | 356T6 Aluminum |
| Construction | Precision Machined |
| Maximum Working Pressure | 150 PSI |
| Approximate Length | 2-11/16" |
| Hex Size | 3-7/32" |
| Interchange Standard | A-A-59326D Compatible |
| Intended Service | Liquid Transfer Applications |
| Service Restriction | Not Recommended for Compressed Air or Steam Service |
Type A Connection Configuration
Male Cam & Groove Adapter
One end features a 2-1/2" male cam and groove adapter designed to connect with a compatible female cam and groove coupler.
2-1/2"-8 Female NPT
The opposite end features a 2-1/2"-8 female NPT threaded connection for attachment to a compatible male threaded system connection.
356T6 Aluminum Construction
The Type A adapter is manufactured from 356T6 aluminum, providing a combination of strength, lightweight handling, and corrosion resistance for compatible liquid transfer systems.
Precision-Machined Design
The fitting features a precision-machined body designed to provide consistent fit and a secure connection with compatible cam and groove and threaded system components.
Maximum Working Pressure
150 PSI
The supplied product information lists a maximum working pressure of 150 PSI. Verify that all mating fittings and system components are appropriately rated for the intended operating conditions.
Dimensions
Approximate Length
The supplied product information lists an approximate overall length of 2-11/16".
Hex Size
The supplied product information lists a hex size of 3-7/32".
A-A-59326D Interchange
The precision-machined body is designed for interchangeability with compatible standard cam and groove components manufactured to A-A-59326D specifications.
Liquid Transfer Applications
This Dixon Type A adapter is designed for liquid transfer applications requiring a transition between a compatible female cam and groove coupler and a male NPT threaded system connection.
Service Restrictions
This fitting is designed for liquid transfer applications only and is not recommended for compressed air or steam service.
Our specialists can help with Type A fitting selection, cam and groove compatibility, NPT connections, pressure requirements, and aluminum camlock applications.
Email the GetPipe.com Team Visit Quick SupportFrequently Asked Questions
What is a Type A cam and groove adapter?
A Type A fitting combines a male cam and groove adapter with a female NPT threaded connection.
What size is this Type A adapter?
The supplied product information identifies this fitting as a 2-1/2" Type A adapter.
What is the female NPT thread size?
The female threaded connection is specified as 2-1/2"-8 FNPT.
What material is this adapter made from?
The fitting is manufactured from 356T6 aluminum.
What is the maximum working pressure?
The supplied product information lists a maximum working pressure of 150 PSI.
What is the approximate length?
The supplied product information lists an approximate length of 2-11/16".
What is the hex size?
The listed hex size is 3-7/32".
Does this adapter interchange with standard camlock fittings?
The supplied product information states that the fitting interchanges with compatible cam and groove components manufactured to A-A-59326D specifications.
What type of service is this fitting designed for?
This Type A adapter is designed for liquid transfer applications.
Can this fitting be used for compressed air or steam?
No. The supplied product information states that the fitting is not recommended for compressed air or steam service.
Important Ordering & Product Notes
- This listing covers a Dixon 2-1/2" Type A Aluminum Male Cam x FNPT Adapter.
- Fitting type is Type A.
- Nominal size is 2-1/2".
- Connection configuration is male cam & groove adapter x female NPT.
- Female thread size is 2-1/2"-8 FNPT.
- Construction material is 356T6 aluminum.
- Maximum working pressure is listed as 150 PSI.
- Approximate length is 2-11/16".
- Hex size is 3-7/32".
- Designed to interchange with compatible camlock fittings manufactured to A-A-59326D specifications.
- The specific manufacturer part number was not supplied in the provided product information.
- Designed for liquid transfer applications only.
- Not recommended for compressed air or steam service.
