Milwaukee
Milwaukee Tool 7" Magnetic Rafter Square
- SKU:
- MLWMLSQM070
- Availability:
- Usually Ships Same Day
- Weight:
- 0.50 LBS
Description
DUTY®
7 in Magnetic Rafter Square
Measure, lay out and mark · Match the tool to the surface and task
Product Overview
This 7 in rafter square uses laser-etched markings and scribe notches for lumber layout.
A machined aluminum body includes a pipe cutout. Rare-earth magnets help hold it on steel.
- Nominal size7 in.
- Scribe range1–6 in.
- MarkingsLaser etched.
- Holding featureRare-earth magnets.
Technical Specifications
- Nominal size
- 7 in
- Construction
- Extruded aluminum
- Scribe range
- 1–6 in
- Pipe cutout
- 1 in
- Heel size
- 1-1/8 in
- Markings
- Laser etched
Choose the Correct Fit
Seat the heel against a clean, straight reference edge and choose the scale appropriate to the layout. Clear chips or burrs that could keep the square from sitting flat.
Rare-earth magnets provide a hold on suitable ferrous material. The pipe cutout is a layout aid, not a clamp; support the work securely before cutting.
Installation & Care
Wipe the body and reference edges clean and avoid dropping or bending the square. Check it against a known square reference if an impact may have affected alignment.
Keep the laser-etched markings readable and protect the edges during storage. Use a sharp marking tool suited to the notch and material rather than forcing it into place.
Small Details. Big Jobsite Energy.
Get set. Stay focused. Make your next move count.
THE NEXT JOB.
Ask Willy:
Need help choosing a layout or marking tool? Tell us the task, surface and measuring system.
Important Product Questions
What scribe range is provided?
The manufacturer specifies scribe notches from 1–6 in for this exact model.
Is this square magnetic?
Yes. This exact model lists rare-earth magnets for holding on suitable ferrous material.
What is the cutout for?
The 1 in cutout can help prop pipe during layout. Secure the pipe appropriately before cutting; the square is not a workholding clamp.
