Milwaukee Tool 180mm Rafter Square
- SKU:
- MLWMLSQ170
- Availability:
- Usually Ships Same Day
- Weight:
- 0.50 LBS
Description
DUTY®
180 mm Rafter Square
Measure, lay out and mark · Match the tool to the surface and task
Product Overview
This 180 mm rafter square uses laser-etched markings and scribe notches for lumber layout.
A machined aluminum body includes a pipe cutout. The heel gives a firm reference at an edge.
- Nominal size180 mm.
- Scribe range25–145 mm.
- MarkingsLaser etched.
- Holding featureReference heel.
Technical Specifications
- Nominal size
- 180 mm
- Construction
- Extruded aluminum
- Scribe range
- 25–145 mm
- Pipe cutout
- 25 mm
- Heel size
- 28.5 mm
- Markings
- Laser etched
Choose the Correct Fit
Seat the heel against a clean, straight reference edge and choose the scale appropriate to the layout. Clear chips or burrs that could keep the square from sitting flat.
Use the scribe notches to guide repeatable offset marks. The pipe cutout is a layout aid, not a clamp; support the work securely before cutting.
Installation & Care
Wipe the body and reference edges clean and avoid dropping or bending the square. Check it against a known square reference if an impact may have affected alignment.
Keep the laser-etched markings readable and protect the edges during storage. Use a sharp marking tool suited to the notch and material rather than forcing it into place.
Small Details. Big Jobsite Energy.
Get set. Stay focused. Make your next move count.
THE NEXT JOB.
Ask Willy:
Need help choosing a layout or marking tool? Tell us the task, surface and measuring system.
Important Product Questions
What scribe range is provided?
The manufacturer specifies scribe notches from 25–145 mm for this exact model.
Is this square magnetic?
No magnetic holding feature is claimed for this metric rafter square. Select an explicitly magnetic model if that feature is needed.
What is the cutout for?
The 25 mm cutout can help prop pipe during layout. Secure the pipe appropriately before cutting; the square is not a workholding clamp.
