SOVAL
803 Series Flanged x Mechanical Joint NRS Gate Valve
- SKU:
- SOVAL 803
- Availability:
- Allow 7-10 Days to Ship from Florida
- Weight:
- 0.00 LBS
Description
SOVAL 803 Series Flanged x Mechanical Joint NRS Gate Valve
The SOVAL 803 Series Non-Rising Stem (NRS) Gate Valve is engineered for dependable waterworks and fire protection service applications requiring rugged construction, long service life, and reliable shutoff performance. Designed with a flanged x mechanical joint connection configuration, this valve is ideal for municipal water systems, underground piping networks, and commercial fire protection installations.
Manufactured with a durable ductile iron body and EPDM encapsulated wedge, the 803 Series provides corrosion resistance, leak-tight sealing, and dependable operation under demanding conditions. The valve features a stainless steel stem, graphite packing, and multiple EPDM O-rings for enhanced durability and sealing integrity.
Product Features
- Flanged x Mechanical Joint connection design
- Non-Rising Stem (NRS) gate valve construction
- Ductile iron body per ASTM A536 65-45-12
- EPDM encapsulated wedge for positive sealing
- 300 PSI pressure rating
- UL Listed and FM Approved
- Stainless steel stem and hardware components
- Ideal for municipal waterworks and fire protection systems
- Available in 3" through 12" sizes
Pressure Rating: 300 PSI
Approvals: UL Listed & FM Approved
Material Construction:
- Body & Bonnet: Ductile Iron ASTM A536 65-45-12
- Stem: Stainless Steel AISI 420
- Bolts: Stainless Steel AISI 304
- Wedge: Ductile Iron EPDM Encapsulated
- Seals & O-Rings: EPDM
Available Sizes: 3", 4", 6", 8", 10", and 12"
