90° Grooved Elbow - Regular Radius
- SKU:
- SJT7110
- Availability:
- Usually Ships Same Day
- Weight:
- 0.00 LBS
Description
90° Grooved Elbow - Regular Radius
Shurjoint 90° Grooved Elbow - Regular Radius is designed for compatible grooved piping systems that require a 90-degree change in direction.
Shurjoint grooved-end elbows are manufactured from ductile iron per ASTM A536 Grade 65-45-12 and/or ASTM A395 Grade 65-45-15. C-E dimensions are manufacturer’s standard, and Shurjoint standard fitting pressure ratings conform to the ratings of Model 7707 couplings.
Product Highlights
- 90° grooved elbow
- Regular-radius configuration
- Grooved-end connections
- Ductile iron construction
- ASTM A536 Grade 65-45-12 and/or ASTM A395 Grade 65-45-15
- C-E dimensions are manufacturer’s standard
- Standard fitting pressure ratings conform to Model 7707 coupling ratings
Technical Specifications
| Manufacturer | Shurjoint |
|---|---|
| Product Type | Grooved Elbow |
| Elbow Angle | 90° |
| Radius | Regular Radius |
| Connection Type | Grooved End |
| Material | Ductile Iron |
| Material Standards | ASTM A536 Grade 65-45-12 and/or ASTM A395 Grade 65-45-15 |
| C-E Dimensions | Manufacturer’s Standard |
| Pressure Rating | Shurjoint standard fitting pressure ratings conform to Model 7707 coupling ratings |
Construction & Design
Ductile Iron Construction
Shurjoint grooved-end elbows are made from ductile iron in accordance with ASTM A536 Grade 65-45-12 and/or ASTM A395 Grade 65-45-15.
90° Regular-Radius Elbow
The elbow provides a 90° change in piping direction using a regular-radius configuration with grooved ends.
Dimensions & Pressure Ratings
C-E Dimensions
C-E dimensions are Shurjoint manufacturer’s standard. Refer to the 7110 - 7113 Elbows Submittal Sheet for applicable dimensional information.
Fitting Pressure Ratings
Shurjoint standard fitting pressure ratings conform to the ratings of Model 7707 couplings. Refer to the applicable Shurjoint technical documentation for pressure-rating information.
Product Documentation
Shurjoint Technical Documents
Use the elbow submittal sheet, Shurjoint technical data, and product catalog for additional dimensional, pressure-rating, and grooved piping system information.
Need Help Selecting a Grooved Elbow?
Our industrial PVF specialists can help confirm fitting size, grooved-system compatibility, pressure requirements, and other application details before you order.
Frequently Asked Questions
What type of fitting is this?
This is a regular-radius 90° grooved-end elbow for compatible grooved piping systems.
What material is the elbow made from?
Shurjoint grooved-end elbows are made from ductile iron per ASTM A536 Grade 65-45-12 and/or ASTM A395 Grade 65-45-15.
What type of connections does the elbow use?
The fitting uses grooved-end connections.
What are the C-E dimensions?
C-E dimensions are Shurjoint manufacturer’s standard. Refer to the 7110 - 7113 Elbows Submittal Sheet for dimensional information.
What pressure rating applies to this fitting?
Shurjoint standard fitting pressure ratings conform to the ratings of Model 7707 couplings.
Where can I find additional technical information?
The 7110 - 7113 Elbows Submittal Sheet, Shurjoint Technical Data, and Shurjoint Product Catalog are linked above.
