316 Stainless Steel Butt Weld 45 Elbow - Sch 10

316/L stainless steel Schedule 10S 45° butt weld elbows provide a smooth directional change in stainless steel piping systems while minimizing pressure loss and turbulence. Manufactured from A/SA403 WP316/L stainless steel, these fittings offer outstanding corrosion resistance and are well suited for demanding industrial and sanitary applications.

Built to ASME B16.9 dimensional standards, these 45-degree elbows are designed for permanent butt weld installation and deliver reliable performance in chemical processing, food and beverage, pharmaceutical, marine, and other corrosive environments.

Key Features

• Manufactured from A/SA403 WP316/L stainless steel
• Schedule 10S wall thickness
• 45° butt weld elbow configuration
• Built to ASME B16.9 dimensional standards
• Excellent corrosion resistance, including chloride-containing environments
• Designed for permanent welded piping systems
• Available in sizes from 1 inch through 10 inch

Construction Details

Manufactured from low-carbon 316/L stainless steel for excellent weldability while reducing the risk of carbide precipitation during welding.

The 45-degree elbow provides an efficient change in flow direction while maintaining smooth fluid movement and reducing system turbulence.

Precision formed to ASME B16.9 requirements for consistent fit-up, dimensional accuracy, and dependable installation.

Important Notes

Designed for use with Schedule 10S stainless steel pipe and compatible butt weld piping systems.

Professional welding procedures should be followed to ensure proper joint integrity and corrosion resistance.

Always verify pipe schedule, material compatibility, pressure ratings, and applicable code requirements before installation.
