316 Stainless Steel 150# Threaded Cross - SP114
- Availability:
- Usually in Stock – Ships Quickly
- Weight:
- 0.00 LBS
Description
316 Stainless Steel 150# Threaded Cross - SP114
Charman 316 Stainless Steel SP114 Threaded Crosses provide four-way connections for compatible threaded piping systems. Manufactured from 316 stainless steel, these fittings are designed to connect four piping directions through a single compact body for plumbing, industrial, process, maintenance, and general piping applications.
The SP114 Cross family shown here is available in nominal sizes from 1/4" through 1-1/2". Each cross uses matching nominal connection sizes at all four openings, making it suitable where multiple piping branches must meet without changing pipe size.
Product Highlights
- SP114 cross design
- Four threaded openings
- 316 stainless steel construction
- Six nominal sizes available
- Designed for four-way piping connections
- Matching nominal connection sizes at all openings
- Available in sizes ranging from 1/4" through 1-1/2"
- Useful for plumbing, industrial, process, and general threaded piping systems
What Is an SP114 Threaded Cross?
A 316 stainless steel SP114 threaded cross is a four-opening fitting used to connect compatible threaded piping components at one common junction. Two openings form the straight-through run while the remaining two provide opposing branch connections.
Each standard cross in this listing uses the same nominal connection size at all four openings. This makes the fitting appropriate where the piping branches need to remain the same nominal size throughout the junction.
Why Choose a 316 Stainless Steel SP114 Threaded Cross?
316 Stainless Steel Construction
- Durable construction
- Enhanced corrosion resistance
- Designed for threaded piping
- Suitable for compatible piping systems
- Useful across industrial and process applications
Four-Way Connection Design
- Four openings
- Threaded connections
- Compact cross configuration
- Matching nominal connection sizes
- Allows multiple piping directions from one junction
Common Applications
Plumbing & General Piping
- Piping repairs
- Branch connections
- Piping modifications
- Four-way pipe junctions
- General-purpose piping installations
Industrial & Process Use
- Equipment piping
- Maintenance work
- Process piping systems
- Industrial piping layouts
- Compatible stainless steel piping installations
Construction Details
316 Stainless Steel Body
- Solid fitting construction
- SP114 cross configuration
- Designed for four-way connections
- Suitable for compatible threaded systems
- 316 stainless steel provides enhanced corrosion resistance for suitable applications
Four Threaded Connections
- Four connection openings
- Cross-shaped fitting body
- Matching nominal connection sizes
- Designed for multidirectional piping layouts
- All mating threads should be confirmed before installation
Available SP114 Cross Sizes
The 316 Stainless Steel 150# Threaded Cross - SP114 is available in 1/4", 3/8", 1/2", 3/4", 1", and 1-1/2" nominal sizes in the SKU set provided. Each size has its own Charman part number for accurate ordering.
All four openings on each standard cross use the same listed nominal size. Match the cross to the required piping size at every connection before ordering.
Cross vs. Tee
SP114 Cross
- Four openings
- Four-way connection
- Two opposing branch directions
- Matching nominal connection sizes
- Used where piping must branch in multiple directions
SP114 Tee
- Three openings
- Three-way connection
- Single branch direction
- Available as a separate fitting
- Used where one branch is required from a piping run
Where a Charman SP114 Cross Makes Sense
- For four-way pipe junctions
- During threaded piping modifications
- For multidirectional branch connections
- Where 316 stainless steel construction is appropriate
- For compatible plumbing, industrial, and process piping systems
- When several same-size piping directions must connect through one threaded fitting body
Installation & Selection Considerations
- Select the cross size that matches the piping.
- Confirm all mating threads are compatible before installation.
- Inspect threaded surfaces for damage, debris, or contamination.
- Use a thread-sealing method appropriate for the intended piping system.
- Verify pressure, temperature, media, material, and installation requirements before use.
Product Selection Considerations
Nominal Size
Select the 316 Stainless Steel 150# Threaded Cross - SP114 according to the required nominal pipe size. The SKU set supplied here includes sizes from 1/4" through 1-1/2".
Connection Layout
Choose a cross where four compatible threaded piping directions need to meet at one junction. Confirm all mating threads and system requirements before ordering.
Review the Charman Inc stainless steel fittings specification sheet for product and dimensional information on the SP114 threaded cross, or use the complete stainless steel fittings catalog to compare available fitting styles, configurations, and sizes before ordering.
Need Help Selecting a Stainless Steel Pipe Fitting?
Our industrial PVF specialists can help review your pipe size, connection type, stainless steel requirements, application, and installation conditions before you order.
Frequently Asked Questions
What material is the SP114 Cross?
Charman identifies this product family as a 316 stainless steel fitting.
Are these crosses threaded?
Yes. These SP114 Crosses are designed for compatible threaded piping connections.
What sizes are included?
The supplied SKU set includes 1/4", 3/8", 1/2", 3/4", 1", and 1-1/2" nominal sizes.
How many connections does a cross provide?
A threaded cross provides four connection openings arranged around one common fitting body.
Are all four connections the same size?
Yes. Each standard cross in this listing uses the same nominal size at all four threaded openings.
Which Charman SKUs are included?
The included part numbers are 316531, 316532, 316533, 316534, 316535, and 316537.
Where can I review Charman stainless steel fitting information?
The Charman Stainless Steel Fittings Spec Sheet and Complete Catalog are linked directly above for additional product and fitting information.
What should I confirm before ordering?
Confirm nominal size, all mating threads, material requirements, pressure, temperature, media, and installation conditions before ordering.
Important Ordering & Installation Notes
- Six nominal sizes are included.
- Match the cross to the required nominal pipe size.
- Review the supplied Charman documents for additional fitting information.
- Confirm all mating threads and sealing requirements before installation.
- Verify material, pressure, temperature, media, connection, and installation requirements before service.
