Dixon
3" Stainless Steel Type C Cam & Groove Coupler x Hose Shank
- SKU:
- NLDIX300-C-SS
- Availability:
- Limited quantity available.
- Weight:
- 4.10 LBS
Description
Dixon NLDIX300-C-SS 3" Stainless Steel Type C Cam & Groove Coupler x Hose Shank
The Dixon NLDIX300-C-SS 3" Type C Cam & Groove Coupler is designed for fast, secure hose connections in compatible liquid transfer applications.
Manufactured from durable 316 stainless steel, this fitting combines a 3" female cam and groove coupler with a 3" hose shank. A Buna-N nitrile gasket, precision-machined sealing surfaces, and stainless steel cam arm pins provide dependable connection and sealing performance in demanding industrial fluid handling systems.
Product Highlights
- SKU: NLDIX300-C-SS
- 3" Type C cam & groove coupler
- 3" female camlock coupler x 3" hose shank
- 316 stainless steel construction
- Maximum operating pressure: 125 PSI at 70°F
- Buna-N nitrile rubber gasket
- Approximate overall length: 6-7/16"
- Precision-machined sealing surfaces
- Stainless steel cam arm pins
- Interchangeable with products meeting A-A-59326D specifications
- Designed for liquid transfer applications
- Not recommended for compressed air or steam service
Technical Specifications
| Brand | Dixon |
|---|---|
| SKU | NLDIX300-C-SS |
| Product Type | Cam & Groove Coupler x Hose Shank |
| Fitting Type | Type C |
| Nominal Size | 3" |
| Connection 1 | 3" Female Cam & Groove Coupler |
| Connection 2 | 3" Hose Shank |
| Body Material | 316 Stainless Steel |
| Gasket Material | Buna-N Nitrile Rubber |
| Cam Arm Pins | Stainless Steel |
| Maximum Operating Pressure | 125 PSI at 70°F |
| Overall Length | Approximately 6-7/16" |
| Construction | Precision Machined |
| Interchange Standard | A-A-59326D |
| Intended Service | Liquid Transfer Applications |
| Service Restriction | Not Recommended for Compressed Air or Steam Service |
Type C Connection Configuration
3" Female Cam & Groove Coupler
The camlock side features a 3" female cam and groove coupler designed for quick connection and disconnection with a compatible male cam and groove adapter.
3" Hose Shank
The opposite end features a 3" hose shank designed to provide a secure attachment point for a compatible hose assembly.
316 Stainless Steel Construction
The NLDIX300-C-SS is manufactured from 316 stainless steel, providing strong corrosion resistance and durability for demanding compatible fluid transfer environments.
The supplied product information identifies industrial, chemical, petroleum, agricultural, and general fluid transfer environments as applications for its stainless steel construction.
Buna-N Nitrile Gasket
The coupler uses a Buna-N nitrile rubber gasket to provide sealing at the cam and groove connection. Verify gasket compatibility with the transferred media and operating conditions before installation.
Stainless Steel Cam Arm Pins
The female camlock coupler incorporates stainless steel cam arm pins for corrosion resistance and dependable performance during repeated connection and disconnection cycles.
Precision-Machined Construction
Precision-machined sealing surfaces help provide proper fitment and reliable sealing performance when the coupler is connected to compatible cam and groove components.
Maximum Operating Pressure
125 PSI at 70°F
The supplied product information lists a maximum operating pressure of 125 PSI at 70°F. Verify the pressure ratings of the hose, coupling, and all other components in the complete transfer system before operation.
Overall Length
Approximately 6-7/16"
The supplied product information lists an approximate overall fitting length of 6-7/16".
A-A-59326D Interchange
The NLDIX300-C-SS is designed to interchange with compatible cam and groove products meeting A-A-59326D specifications.
Typical Applications
- Industrial liquid transfer
- Compatible chemical transfer systems
- Compatible petroleum fluid handling
- Agricultural fluid transfer
- General fluid handling systems
- Cam and groove hose assemblies
- Hose-to-camlock connections
Hose Assembly & Service Notes
This Type C coupling is intended for liquid transfer applications. Verify hose compatibility, Buna-N gasket compatibility, system pressure requirements, and mating cam and groove components before installation.
The supplied product information states that the NLDIX300-C-SS is not recommended for compressed air or steam service.
Our specialists can help with Type C fitting selection, cam and groove compatibility, hose connections, pressure requirements, and Buna-N gasket compatibility for your liquid transfer system.
Email the GetPipe.com Team Visit Quick SupportFrequently Asked Questions
What is the Dixon NLDIX300-C-SS?
The NLDIX300-C-SS is a 3" stainless steel Type C cam and groove coupler featuring a female camlock connection on one end and a hose shank on the other.
What are the connection sizes?
The fitting combines a 3" female cam and groove coupler with a 3" hose shank.
What does the female camlock end connect to?
The female cam and groove coupler is designed to connect with a compatible male cam and groove adapter.
What material is the coupler made from?
The body is manufactured from 316 stainless steel.
What gasket does the NLDIX300-C-SS use?
The supplied product information identifies a Buna-N nitrile rubber gasket.
What is the maximum operating pressure?
The supplied product information lists a maximum operating pressure of 125 PSI at 70°F.
What is the overall length?
The supplied product information lists an approximate overall length of 6-7/16".
What material are the cam arm pins?
The cam arm pins are identified as stainless steel.
Does this coupler interchange with standard cam and groove fittings?
The supplied product information states that it is interchangeable with compatible products meeting A-A-59326D specifications.
What applications is this Type C coupler designed for?
The supplied information identifies compatible industrial, chemical, petroleum, agricultural, and general liquid transfer applications.
Can the NLDIX300-C-SS be used for compressed air or steam?
No. The supplied product information states that this coupling is intended for liquid transfer applications and is not recommended for compressed air or steam service.
Important Ordering & Product Notes
- This listing covers the Dixon NLDIX300-C-SS 3" Stainless Steel Type C Cam & Groove Coupler x Hose Shank.
- Fitting type is Type C.
- Connection configuration is 3" female cam & groove coupler x 3" hose shank.
- Body material is 316 stainless steel.
- Gasket material is Buna-N nitrile rubber.
- Cam arm pins are stainless steel.
- Maximum operating pressure is listed as 125 PSI at 70°F.
- Approximate overall length is 6-7/16".
- Designed to interchange with compatible products meeting A-A-59326D specifications.
- Designed for liquid transfer applications.
- Specific product weight and additional dimensional measurements were not supplied in the provided product information.
- Verify hose compatibility, gasket material compatibility, pressure requirements, and mating fitting compatibility before installation.
- Not recommended for compressed air or steam service.
