Dixon
1-1/4" Aluminum Type D Camlock Coupler
- SKU:
- NLDIX125-D-AL
- Availability:
- Limited quantity available.
- Weight:
- 1.00 LBS
Description
Dixon 125-D-AL 1-1/4" Aluminum Type D Camlock Coupler x Female NPT
The Dixon 125-D-AL 1-1/4" Type D Cam & Groove Coupler is designed for liquid transfer systems requiring fast connection and disconnection between compatible camlock components and female NPT threaded connections.
This Type D fitting combines a 1-1/4" female cam coupler with a 1-1/4" female NPT connection. Manufactured from 356T6 aluminum, the 125-D-AL features a nitrile rubber / Buna-N gasket, stainless steel cam arm pins, precision-machined construction, and a gasket recess to support proper seal placement.
Product Highlights
- Dixon Type D cam and groove coupler
- Manufacturer part number: 125-D-AL
- SKU: NLDIX125-D-AL
- 1-1/4" female cam x 1-1/4" female NPT connection
- 356T6 aluminum body
- Nitrile rubber / Buna-N gasket
- Stainless steel cam arm pins
- Precision-machined construction
- Gasket recess supports proper seal placement
- Long shank design for proper banding
- Maximum operating pressure: 250 PSI at ambient temperature with standard seal
- Produced to interchange with products made to Commercial Item Description A-A-59326D
- Designed for liquid transfer use only
- Not for compressed air or steam service
Technical Specifications
| Brand | Dixon Valve & Coupling |
|---|---|
| Manufacturer Part Number | 125-D-AL |
| SKU | NLDIX125-D-AL |
| Fitting Type | Type D Cam & Groove Coupler |
| Nominal Size | 1-1/4" |
| Connection 1 | 1-1/4" Female Cam Coupler |
| Connection 2 | 1-1/4" Female NPT |
| Body Material | 356T6 Aluminum |
| Seal / Gasket | Nitrile Rubber / Buna-N |
| Cam Arm Pins | Stainless Steel |
| Maximum Operating Pressure | 250 PSI at Ambient Temperature with Standard Seal |
| Interchange Standard | Commercial Item Description A-A-59326D |
| Intended Service | Liquid Transfer |
| Service Restriction | Do Not Use for Compressed Air or Steam |
Type D Connection Configuration
1-1/4" Female Cam Coupler
The cam and groove side features a 1-1/4" female cam coupler for fast connection and disconnection with compatible male camlock adapters.
1-1/4" Female NPT
The opposite end features a 1-1/4" female NPT threaded connection for connection to compatible male threaded piping, fittings, and fluid handling components.
356T6 Aluminum Construction
The 125-D-AL features a 356T6 aluminum body for lightweight durability in compatible industrial fluid handling systems. The aluminum body is precision machined for dependable fit and performance with compatible cam and groove components.
Buna-N Gasket & Gasket Recess
The coupler includes a nitrile rubber / Buna-N gasket. A gasket recess helps maintain proper seal placement during connection for dependable sealing performance with compatible cam and groove components.
Stainless Steel Cam Arm Pins
The supplied product information identifies stainless steel cam arm pins that support reliable coupling operation during connection and disconnection.
Long Shank Design
The supplied product information identifies a long shank design intended to support proper banding when the fitting is used with compatible hose assemblies.
Maximum Operating Pressure
250 PSI at Ambient Temperature with Standard Seal
The supplied product information lists a maximum operating pressure of 250 PSI at ambient temperature with the standard seal. System pressure must also account for the ratings of all connected components.
A-A-59326D Interchange
The Dixon 125-D-AL is produced to interchange with compatible products made to Commercial Item Description A-A-59326D.
Liquid Transfer Service
The 125-D-AL is designed for liquid transfer use only. Its female camlock connection provides quick coupling with compatible cam and groove adapters, while the female NPT connection provides integration with compatible threaded fluid handling components.
Service Restrictions
Do not use this cam and groove coupling for compressed air or steam service. The supplied product information identifies the 125-D-AL specifically for liquid transfer applications.
Our specialists can help with connection compatibility, gasket material, pressure requirements, and application questions for the Dixon 125-D-AL 1-1/4" Aluminum Type D Cam & Groove Coupler.
Email the GetPipe.com Team Visit Quick SupportFrequently Asked Questions
What is the Dixon 125-D-AL?
The 125-D-AL is a 1-1/4" aluminum Type D cam and groove coupler with a female camlock connection and female NPT threaded connection.
What connections does the 125-D-AL have?
The fitting has a 1-1/4" female cam x 1-1/4" female NPT connection configuration.
What material is the 125-D-AL made from?
The body is manufactured from 356T6 aluminum.
What gasket does the 125-D-AL use?
The supplied product information identifies a nitrile rubber / Buna-N gasket.
What is the maximum operating pressure?
The supplied product information lists a maximum operating pressure of 250 PSI at ambient temperature with the standard seal.
What are the cam arm pins made from?
The cam arm pins are identified as stainless steel.
What is the purpose of the gasket recess?
The gasket recess helps maintain proper seal placement during connection.
What standard does the 125-D-AL interchange with?
The supplied product information states that it is produced to interchange with compatible products made to Commercial Item Description A-A-59326D.
What is the 125-D-AL designed to transfer?
The supplied product information identifies the fitting for liquid transfer use.
Can the 125-D-AL be used for compressed air or steam?
No. The supplied product information specifically states not to use cam and groove couplings for compressed air or steam service.
Important Ordering & Product Notes
- This listing covers the Dixon 125-D-AL 1-1/4" Aluminum Type D Camlock Coupler.
- Manufacturer part number: 125-D-AL.
- SKU: NLDIX125-D-AL.
- Connection configuration is 1-1/4" female cam x 1-1/4" female NPT.
- Body construction is listed as 356T6 aluminum.
- The supplied configuration includes a nitrile rubber / Buna-N gasket and stainless steel cam arm pins.
- Maximum operating pressure is 250 PSI at ambient temperature with the standard seal.
- The fitting is produced to interchange with compatible products made to Commercial Item Description A-A-59326D.
- The supplied product information identifies this fitting for liquid transfer use only.
- Do not use for compressed air or steam service.
