Dixon
1-1/2" Aluminum Type C Cam & Groove Coupler x Hose Shank
- SKU:
- NLDIX150-C-AL
- Availability:
- Limited quantity available.
- Weight:
- 1.00 LBS
Description
Dixon 150-C-AL 1-1/2" Aluminum Type C Cam & Groove Coupler x Hose Shank
The Dixon 150-C-AL 1-1/2" Type C Cam & Groove Coupler is designed for quick connection and disconnection of compatible hose assemblies in industrial liquid transfer applications.
This Type C fitting combines a female cam & groove coupler with a hose shank / hose barb connection. Manufactured from durable 356T6 aluminum, the 150-C-AL features precision-machined construction, stainless steel cam arm pins, and a Buna-N nitrile rubber gasket for dependable connection and sealing performance.
Product Highlights
- Dixon 1-1/2" Type C cam and groove coupler
- Manufacturer part number: 150-C-AL
- Female cam & groove coupler x hose shank connection
- 356T6 aluminum construction
- Buna-N nitrile rubber gasket
- Stainless steel cam arm pins
- Precision-machined construction for reliable fit and sealing
- Maximum operating pressure: 250 PSI
- Approximate length: 4-7/8"
- Interchangeable with compatible cam and groove fittings manufactured to A-A-59326 standards
- Designed for liquid transfer applications only
- Not for compressed air or steam service
Technical Specifications
| Brand | Dixon |
|---|---|
| Manufacturer Part Number | 150-C-AL |
| Product Type | Cam & Groove Coupler |
| Fitting Type | Type C |
| Nominal Size | 1-1/2" |
| Connection 1 | Female Cam & Groove Coupler |
| Connection 2 | Hose Shank / Hose Barb |
| Material | 356T6 Aluminum |
| Gasket Material | Nitrile Rubber / Buna-N |
| Cam Arm Pins | Stainless Steel |
| Maximum Operating Pressure | 250 PSI |
| Approximate Length | 4-7/8" |
| Interchange Standard | A-A-59326 |
| Designed For | Liquid Transfer Applications |
| Service Restriction | Not for Compressed Air or Steam Service |
Type C Connection Configuration
Female Cam & Groove Coupler
The coupling end features a 1-1/2" female cam & groove connection for quick connection and disconnection with a compatible male camlock adapter.
Hose Shank Connection
The opposite end features a hose shank / hose barb connection for attachment to a compatible hose assembly.
356T6 Aluminum Construction
The Dixon 150-C-AL is manufactured from 356T6 aluminum, providing durable construction for compatible industrial liquid transfer applications.
Buna-N Nitrile Rubber Gasket
The coupler includes a Buna-N nitrile rubber gasket to support dependable sealing when the female camlock coupler is connected with a compatible male cam and groove adapter.
Stainless Steel Cam Arm Pins
The 150-C-AL features stainless steel cam arm pins as part of its coupling design, supporting durable operation during repeated connection and disconnection.
Precision-Machined Construction
The fitting features precision-machined construction designed to support reliable fit and sealing with compatible cam and groove components.
Fitting Length
The supplied product information lists an approximate fitting length of 4-7/8".
Maximum Operating Pressure
250 PSI Maximum
The supplied product information lists a maximum operating pressure of 250 PSI. Verify the pressure ratings of the hose and all other connected components when determining the allowable operating pressure of the complete assembly.
A-A-59326 Interchange
The Dixon 150-C-AL is identified as interchangeable with compatible standard cam and groove fittings manufactured to A-A-59326 standards.
Liquid Transfer Service
The Dixon 150-C-AL is designed for liquid transfer applications only. Verify compatibility with the hose, transferred media, pressure requirements, and operating conditions before installation.
Service Restrictions
Under no circumstances should cam and groove couplings be used for compressed air or steam service.
Our specialists can help with camlock compatibility, hose connections, gasket selection, pressure requirements, and application questions for the Dixon 150-C-AL 1-1/2" Aluminum Type C Cam & Groove Coupler.
Email the GetPipe.com Team Visit Quick SupportFrequently Asked Questions
What is the Dixon 150-C-AL?
The 150-C-AL is a 1-1/2" Type C aluminum cam and groove coupler featuring a female camlock connection and a hose shank connection.
What connections does the 150-C-AL have?
The fitting has a female cam & groove coupler on one end and a hose shank / hose barb connection on the other.
What material is the 150-C-AL made from?
The coupler is manufactured from 356T6 aluminum.
What gasket does the 150-C-AL use?
The supplied product information identifies a Buna-N nitrile rubber gasket.
What material are the cam arm pins?
The cam arm pins are stainless steel.
What is the maximum operating pressure?
The supplied product information lists a maximum operating pressure of 250 PSI.
How long is the 150-C-AL?
The supplied product information lists an approximate length of 4-7/8".
What standard does the 150-C-AL interchange with?
The supplied product information identifies the fitting as interchangeable with compatible cam and groove fittings manufactured to A-A-59326 standards.
What service is the 150-C-AL designed for?
The supplied product information identifies the coupler for liquid transfer applications only.
Can the 150-C-AL be used for compressed air or steam?
No. The supplied product information states that cam and groove couplings should not be used for compressed air or steam service.
Important Ordering & Product Notes
- This listing covers the Dixon 150-C-AL 1-1/2" Aluminum Type C Cam & Groove Coupler x Hose Shank.
- Manufacturer part number: 150-C-AL.
- Nominal size is 1-1/2".
- Connection configuration is female cam & groove coupler x hose shank / hose barb.
- Construction material is 356T6 aluminum.
- Gasket material is Buna-N nitrile rubber.
- Cam arm pins are stainless steel.
- Maximum operating pressure is listed as 250 PSI.
- Approximate fitting length is 4-7/8".
- Interchangeability is identified with compatible cam and groove fittings manufactured to A-A-59326 standards.
- Designed for liquid transfer applications only.
- Verify compatibility with the hose, media, pressure rating, and operating conditions before installation.
- Do not use cam and groove couplings for compressed air or steam service.
