Schedule 80 CPVC Bullhead Tee (SOC)
Schedule 80 CPVC Bullhead Tee (SOC) provides a three-way connection with a larger branch connection than the straight-through run connections. The socket configuration allows compatible CPVC piping to transition through a specialized bullhead tee arrangement.
The Schedule 80 CPVC bullhead tee combines durable CPVC construction with solvent-cement socket connections for a compact three-way transition. Selection should account for all connection sizes, branch orientation, socket compatibility, piping alignment, system requirements, and proper CPVC joining procedures.
Product Highlights
- CPVC construction
- Schedule 80 design
- Bullhead tee configuration
- Three socket connections
- Straight-through run connections
- Larger-size branch outlet
- Provides a three-way piping transition
- Designed for compatible solvent-cement CPVC piping
Technical Specifications
| Product Type | Bullhead Tee |
|---|---|
| Material | CPVC |
| Schedule | Schedule 80 |
| Configuration | Bullhead Tee |
| Connection | Socket (SOC) |
| Socket Interface | Compatible CPVC Pipe |
| Connection Count | Three Connections |
| Branch Configuration | Larger-Size Socket Branch |
| Joining Method | CPVC Solvent-Cement Connections |
| Primary Function | Provide a Larger Branch Connection from a Smaller CPVC Run |
Bullhead Tee Design
The bullhead tee design provides a straight-through run with a branch connection that is larger than the run connections. This configuration creates a specialized transition within compatible Schedule 80 CPVC piping systems.
All connection sizes should be confirmed before ordering because bullhead tees contain more than one nominal connection size. Proper orientation should also be established before the solvent-cement connections are assembled.
Socket Connections
The socket connections are designed to accept appropriately sized compatible CPVC pipe. The two run sockets maintain the primary piping path while the larger socket provides the branch connection.
Pipe ends and fitting sockets should be clean and properly prepared before assembly. Compatible CPVC primer, solvent cement, insertion procedures, and required cure times should be followed for each connection.
Larger Branch Connection
The larger branch outlet distinguishes the bullhead tee from a conventional reducing tee. This arrangement allows a larger CPVC connection to branch from smaller straight-through run connections.
Both the run sizes and larger branch size should match the adjoining CPVC pipe. Confirming all connection sizes before installation helps prevent incorrect fitting selection and unnecessary changes during assembly.
Schedule 80 CPVC Application
A Schedule 80 CPVC Bullhead Tee provides a molded branch transition for compatible CPVC piping installations. Its socket connections are intended for properly prepared solvent-cement joints using materials suitable for the CPVC piping system.
System temperature, pressure, fluid compatibility, joining requirements, and applicable installation standards should be reviewed for the intended application. Proper piping support and alignment should be maintained so unnecessary mechanical stress is not transferred to the fitting.
Installation & Selection Considerations
- Confirm all nominal sizes.
- Verify the bullhead configuration.
- Identify the larger branch size.
- Check compatible CPVC pipe sizing.
- Maintain proper piping alignment and support.
Our piping specialists can help review the run sizes, larger branch size, socket configuration, CPVC pipe compatibility, joining requirements, and installation considerations before you order.
Frequently Asked Questions
What is a Schedule 80 CPVC Bullhead Tee used for?
It provides a three-way connection where the branch connection is larger than the straight-through run connections.
What makes this a bullhead tee?
A bullhead tee has a branch connection that is larger than the run connections.
What does SOC mean?
SOC identifies a socket connection designed to accept compatible CPVC pipe for solvent-cement joining.
How many connections does this bullhead tee have?
The fitting has three socket connections consisting of two run connections and one larger branch connection.
How are the socket connections joined?
The sockets are designed for compatible CPVC solvent-cement joining using appropriate pipe preparation, primer, solvent cement, insertion procedures, and cure requirements.
What should I confirm before ordering?
Confirm the run sizes, larger branch size, Schedule 80 CPVC material, socket configuration, adjoining pipe sizes, and requirements of the intended piping system.
Important Ordering & Installation Notes
- Confirm all connection sizes.
- Verify the bullhead configuration.
- Confirm Schedule 80 CPVC compatibility.
- Check branch orientation before joining.
- Use compatible CPVC joining materials and procedures.
