Milwaukee
Milwaukee Tool Selfeed Bit 2-1/8"
- SKU:
- MLW48-25-2122
- Availability:
- Usually Ships Same Day
- Weight:
- 0.80 LBS
Description
DUTY®
Standard Selfeed
Wood Boring Bit
Cut 2-1/8 in wood openings for pipe and conduit with a resharpenable, self-feeding bit.
Product Overview
The 2-1/8-inch cutting plane shaves wood openings as the center screw draws the bit forward.
A rust-inhibiting coat protects the bit; renew the removable feed screw when it is worn.
- Center feed screwPulls the bit into the wood.
- Inside cutting planeShaves a smooth hole wall.
- Resharpenable edgeRestore the cutter as it wears.
- Rust-inhibiting coatProtects the stored bit.
Technical Specifications
- Hole diameter
- 2-1/8 in
- Shank size
- 7/16 in
- Feed screw
- Removable, replaceable
- Cutting edge
- Resharpenable
- Finish
- Rust inhibitor
- Work material
- Wood
Choose the Correct Fit
Choose the hole diameter from the pipe or conduit installation requirements, allowing for any required clearance.
Check for concealed services and metal. Confirm the drill’s wood-boring capacity and use its required support handle.
Installation & Care
Secure the work and control the self-feeding pull. Do not force a dull cutter through the material.
Disconnect power before service. Inspect the cutting edge and replace damaged feed screws using the correct parts.
Small Details. Big Jobsite Energy.
Get set. Stay focused. Make your next move count.
THE NEXT JOB.
Ask Willy:
Need to size a pipe or conduit opening? Send Willy the required hole diameter, material and drill model.
Important Product Questions
Can the cutting edge be sharpened?
Yes. This standard Selfeed design has a resharpenable cutting edge. Preserve its geometry and follow the manufacturer’s service guidance.
Can I replace a damaged feed screw?
Yes. The feed screw is removable and replaceable. Match the service part to this bit’s diameter and model.
Does pipe size directly equal the bit diameter?
Not necessarily. Choose the hole from the installation’s actual outside diameter and required clearance, rather than the nominal pipe size alone.
