Milwaukee
Milwaukee Tool 8-44 TPI SAE Thread Gauge
- SKU:
- MLW49-57-5011
- Availability:
- Usually Ships Same Day
- Weight:
- 0.06 LBS
Description
DUTY®
8–44 TPI
SAE Thread Gauge
Match a threaded part to the correct pitch before choosing a tap, die or replacement fastener.
Product Overview
Precision leaves compare to the thread profile. Read the matching pitch from stamped marks.
The metal gauge folds for storage. Check external threads or accessible tapped-hole threads.
- Pitch range8–44 TPI coverage.
- Leaf selection18 measuring leaves.
- Readable marksStamped size identification.
- Compact storageFoldable metal construction.
Technical Specifications
- Range
- 8–44 TPI
- Measuring leaves
- 18
- Sizing
- SAE
- Construction
- Metal
- Storage form
- Folding leaves
- Size marks
- Stamped
Choose the Correct Fit
Confirm whether the thread uses SAE threads-per-inch or metric pitch before selecting the gauge.
Clean the thread and compare leaves until the teeth sit evenly in the grooves without forcing.
Installation & Care
Use the stamped leaf marking as the pitch reference. Check the nominal diameter separately when selecting a tap or die.
Wipe the leaves clean after use and fold them back for storage. Avoid bending or damaging the measuring edges.
Small Details. Big Jobsite Energy.
Get set. Stay focused. Make your next move count.
THE NEXT JOB.
Ask Willy:
Need help identifying a thread? Tell Willy the gauge reading, measured diameter and the part you are matching.
Important Product Questions
Does this measure thread diameter too?
The leaves compare thread pitch. Measure the nominal diameter separately to identify the full thread size.
What can I check with it?
Milwaukee lists screws, bolts, pipes and tapped holes among the intended thread-checking applications.
Which measurement range does it cover?
The SAE gauge covers 8–44 TPI with 18 leaves. Read the exact value stamped on the leaf that matches.
