Milwaukee
Milwaukee Tool .047" Convertible Snap Ring Pliers - 45 Degree
- SKU:
- MLW48-22-6534
- Availability:
- Usually Ships Same Day
- Weight:
- 0.26 LBS
Description
DUTY®
.047" Tips · 45°
Snap Ring Pliers
.047-inch fixed tips at 45° for snap-ring service where the ring holes and access path call for that exact combination.
Product Overview
Match the fixed .047-inch, 45-degree tips to the snap-ring holes and check the entry path.
Set the all-metal dial for internal or external rings before engaging them, then confirm the mode.
- Mode selectionDial selects the ring mode.
- Fixed-tip controlFixed tips engage ring holes.
- Slip-resistant gripDouble-dipped control grips.
- Black oxide finishCorrosion-resistant coating.
Technical Specifications
- Tip diameter
- .047 in
- Tip angle
- 45°
- Ring modes
- Internal / external
- Tip construction
- Fixed
- Grip
- Double-dipped
- Finish
- Black oxide
Choose the Correct Fit
Identify whether the retaining ring sits in a bore or on a shaft. Set the conversion dial for that ring type before applying force.
Choose tips that fully engage both ring holes without forcing them. Check that the chosen angle clears the surrounding housing.
Installation & Care
Wear eye protection and control the ring during removal. Move it only enough to clear the groove; excessive travel can distort it.
Clean the groove and inspect the ring and tips before reassembly. Confirm the ring is fully seated around the groove before returning the assembly to service.
Small Details. Big Jobsite Energy.
Get set. Stay focused. Make your next move count.
THE NEXT JOB.
Ask Willy:
Need help choosing? Tell Willy your material, required size and working clearance so the GetPipe team can check the fit.
Important Product Questions
Does the tip diameter specify the ring size?
No. Tip diameter describes the pins that enter the ring holes. Check the ring manufacturer’s plier and working-range requirements as well as access.
How do I choose between the tip angles?
Choose the angle that allows both tips to engage fully while keeping the handles clear of the housing. A different angle solves access, not an incorrect tip diameter.
How far should I spread or compress the ring?
Move it only enough to pass the shaft or bore shoulder, following the ring manufacturer’s instructions. Replace distorted rings instead of forcing them back into service.
