Empire Industries
Hot Dip Galvanized Adjustable Pipe Roll Stand 12"-14"
- SKU:
- 280SG1214
- Availability:
- Usually Ships in 1-2 Days
- Weight:
- 48.00 LBS
Description
Hot Dip Galvanized Adjustable Pipe Roll Stand 12"-14"
Empire Industries 280S1214 Adjustable Pipe Roll Stand is designed to support 12" through 14" piping while accommodating longitudinal movement caused by thermal expansion and contraction.
The adjustable roller support helps maintain pipe alignment while reducing friction during pipe movement. This configuration features a hot dip galvanized finish for enhanced corrosion resistance and is intended for commercial, industrial, mechanical, and process piping installations.
Product Highlights
- Empire Industries Figure 280S adjustable pipe roll stand
- Model: 280S1214
- Designed for 12" through 14" nominal pipe sizes
- Hot dip galvanized finish for corrosion resistance
- Allows longitudinal pipe movement caused by expansion and contraction
- Adjustable support height for installation flexibility
- Heavy-duty cast iron roller construction
- Carbon steel chair, base plate, and axle assembly
- Maximum recommended load: 3,075 lbs
- Approximate weight: 40 lbs
- Complies with MSS SP-58 and MSS SP-69 requirements
Adjustable Roller Support
The Figure 280S uses a cast iron roller mounted within a heavy-duty steel support assembly. The adjustable design allows the support height to be positioned for the required pipe elevation while maintaining proper alignment.
Technical Specifications
| Manufacturer | Empire Industries |
|---|---|
| Figure | 280S |
| Model | 280S1214 |
| Product Type | Adjustable Pipe Roll Stand |
| Pipe Size | 12"-14" |
| Finish | Hot Dip Galvanized |
| Roller Construction | Cast Iron |
| Chair, Base Plate & Axle | Carbon Steel |
| Maximum Recommended Load | 3,075 lbs |
| Approximate Weight | 40 lbs |
| Compliance | MSS SP-58 and MSS SP-69 |
Pipe Movement
The roller design allows longitudinal movement of the supported pipe as the piping system expands and contracts. This reduces friction and helps limit stress transferred through the piping system during thermal movement.
Hot Dip Galvanized Finish
The hot dip galvanized finish provides corrosion resistance for the steel components and makes this configuration suitable for demanding indoor and outdoor mechanical piping installations.
Construction Details
The pipe roll stand combines a heavy-duty cast iron roller with a carbon steel chair, base plate, and axle assembly. The configuration provides adjustable support for 12" through 14" piping with a maximum recommended load of 3,075 lbs.
Important Ordering Notes
This listing is for the 280S1214 hot dip galvanized adjustable pipe roll stand for 12"-14" pipe. Verify pipe size, insulation requirements, support spacing, required elevation, and load conditions before ordering or installation.
Product Questions
What pipe sizes does the 280S1214 support?
This configuration is designed for 12" through 14" nominal pipe sizes.
What is the maximum recommended load?
The maximum recommended load is 3,075 lbs.
What finish does this pipe roll stand have?
This listing is for the hot dip galvanized configuration.
What is the roller made from?
The roller is constructed of cast iron. The chair, base plate, and axle assembly are carbon steel.
Why is a roller used for the pipe support?
The roller allows longitudinal pipe movement associated with thermal expansion and contraction while maintaining support and alignment.
Is the support height adjustable?
Yes. The Figure 280S is an adjustable pipe roll stand designed to accommodate varying pipe elevations during installation.
What is the approximate weight?
The approximate weight is 40 lbs.
