Harris
E309-16 Stainless Steel Stick Welding Electrode
- Availability:
- Usually in Stock – Ships Quickly
- Weight:
- 0.00 LBS
Description
Harris E309-16 Stainless Steel Stick Welding Electrode
Harris E309-16 stainless steel stick welding electrode is designed for SMAW / stick welding of stainless steels with similar composition in wrought or cast form. It may also be used for welding Type 304 and similar stainless steels where severe corrosion conditions exist and for selected dissimilar-steel welding applications.
Select the required electrode diameter from the product options above. Both available variations are supplied in 10 lb tubes and are tied to the corresponding Harris item number, package weight, selling price and cost.
Product Highlights
- E309-16 stainless steel covered stick electrode
- Designed for SMAW / stick welding
- Suitable for stainless steels of similar composition in wrought or cast form
- May be used with Type 304 and similar stainless steels in severe corrosion conditions
- May be used for selected dissimilar-steel welding applications
- Available in 3/32" and 1/8" electrode diameters
- Both variations supplied in 10 lb tubes
- 86,000 psi tensile strength in the as-welded condition
- 57,000 psi yield strength in the as-welded condition
- 47% elongation in the as-welded condition
- 68% reduction of area in the as-welded condition
- Suitable for all welding positions
Technical Specifications
| Classification | E309-16 |
|---|---|
| Electrode Type | 309-16 Stainless Steel Covered Electrode |
| Welding Process | SMAW / Stick Welding |
| Primary Applications | Similar-composition stainless steels, Type 304 and similar stainless steels, and selected dissimilar-steel applications |
| Available Diameters | 3/32" and 1/8" |
| Package | 10 lb Tube |
| Welding Positions | All Positions |
| Manufacturer | The Harris Products Group |
As-Welded Mechanical Properties
| Tensile Strength | 86,000 psi |
|---|---|
| Yield Strength | 57,000 psi |
| Elongation | 47% |
| Reduction of Area | 68% |
| Rockwell Hardness | 85 HRB |
| Brinell Hardness | 160 HB |
| Charpy V-Notch Impact | 105 ft-lb at Room Temperature |
Available Diameters & Packaging
| Electrode Diameter | Package | Harris Item Number |
|---|---|---|
| 3/32" | 10 lb Tube | 3091650 |
| 1/8" | 10 lb Tube | 3091660 |
Common Applications
Stainless Steel Fabrication
- General stainless steel fabrication
- Type 304 stainless steel
- Stainless steel equipment
- Industrial fabrication
- Stainless steel components
Dissimilar Metals & Repair
- Selected dissimilar-steel joints
- Plant maintenance
- Industrial repair
- Field welding
- Severe corrosion-service applications
Why Choose E309-16 Stick Electrodes?
Versatile Stainless Electrode
E309-16 is used for welding stainless steels of similar composition and may also be suitable for Type 304 and related stainless steels where severe corrosion conditions exist.
Dissimilar-Steel Applications
E309-16 may be used for selected dissimilar-steel joints. Confirm filler-metal compatibility with the applicable welding procedure, engineering specification and materials being joined.
Product Selection Considerations
Electrode Diameter
Select the electrode diameter appropriate for the base-metal thickness, joint design, welding position, amperage range and applicable welding procedure.
Base-Metal Compatibility
Confirm that E309-16 filler metal is appropriate for the materials being joined, particularly when welding dissimilar steels or components exposed to severe corrosion conditions.
Product Resources
View manufacturer-published technical information, specifications, application guidance and product data for Harris 309-16 stainless steel SMAW / stick welding electrodes.
View Harris Product InformationNeed Help Selecting Harris E309-16 Stainless Steel Electrodes?
Our welding and industrial supply specialists can help you select the appropriate electrode diameter and verify filler-metal compatibility for your stainless or dissimilar-steel stick-welding application.
Frequently Asked Questions
What is Harris E309-16 stainless steel stick electrode?
Harris E309-16 is a covered stainless steel electrode designed for SMAW / stick welding of stainless steels with similar composition in wrought or cast form.
Can E309-16 be used with Type 304 stainless steel?
Yes. Harris identifies this filler-metal family for Type 304 and similar stainless steels where severe corrosion conditions may exist.
Can E309-16 be used to weld dissimilar steels?
It may be used for selected dissimilar-steel applications. Confirm the filler-metal selection with the applicable welding procedure and engineering requirements.
What welding process is used with E309-16?
This product is designed for shielded metal arc welding, commonly referred to as SMAW or stick welding.
What electrode diameters are available?
This Harris product is available in 3/32" and 1/8" electrode diameters.
What package size is available?
Both available variations are supplied in nominal 10 lb tubes.
What is the tensile strength of Harris 309-16?
Harris lists an as-welded tensile strength of approximately 86,000 psi.
What is the yield strength of Harris 309-16?
Harris lists an as-welded yield strength of approximately 57,000 psi.
Can Harris 309-16 be welded in all positions?
Yes. Harris identifies this electrode for all welding positions.
How do I choose the correct Harris E309-16 variation?
Select the electrode diameter required for your welding procedure and application. The selected variation determines the Harris item number, package weight, selling price and cost.
Important Ordering Notes
- Select the required electrode diameter before adding the product to your cart.
- Both available variations are supplied in nominal 10 lb tubes.
- The selected variation determines the Harris item number, package weight, selling price and cost.
- Confirm E309-16 filler-metal compatibility with the materials being joined before welding.
- Pay particular attention to welding-procedure requirements when joining dissimilar steels.
- Verify all welding procedure, specification, code and project requirements before use.
- Always follow applicable welding procedures, manufacturer instructions and workplace safety requirements.
