Harris
E308L-16 Stainless Steel Stick Welding Electrode
- Availability:
- Usually in Stock – Ships Quickly
- Weight:
- 0.00 LBS
Description
Harris E308L-16 Stainless Steel Stick Welding Electrode
Harris E308L-16 stainless steel stick welding electrodes are low-carbon stainless covered electrodes designed for SMAW / stick welding of base metals with similar composition, including AISI Types 301, 302, 304, 305 and 308 as well as corresponding low-carbon grades. The low carbon content helps increase resistance to intergranular corrosion by reducing carbide precipitation.
Select the required electrode diameter and tube size from the product options above. Each available variation is tied to the corresponding Harris manufacturer part number, package weight, selling price and cost.
Product Highlights
- E308L-16 stainless steel covered stick electrode
- Designed for SMAW / stick welding
- For compatible 301, 302, 304, 305, 308 and related low-carbon stainless steels
- Maximum carbon content of approximately 0.04%
- Titania-type coating
- Suitable for AC or DC reverse-polarity operation
- Available in 1/16", 3/32", 1/8" and 5/32" diameters
- Available in 5 lb and 10 lb tube packages
- Conforms to ANSI/AWS A5.4 and ASME SFA 5.4 E308L-16
Technical Specifications
| AWS Classification | E308L-16 |
|---|---|
| Electrode Type | Low-Carbon Stainless Steel Covered Electrode |
| Welding Process | SMAW / Stick Welding |
| Primary Base-Metal Family | Compatible 301, 302, 304, 305, 308 and Related Low-Carbon Stainless Steels |
| Available Diameters | 1/16", 3/32", 1/8" and 5/32" |
| Package Type | Tube |
| Carbon Content | 0.04% Maximum |
| Coating | Titania Type |
| Current | AC or DC Reverse Polarity |
| Specification | ANSI/AWS A5.4 & ASME SFA 5.4 E308L-16 |
| Manufacturer | The Harris Products Group |
As-Welded Mechanical Properties
| Tensile Strength | 84,000 psi |
|---|---|
| Yield Strength | 64,000 psi |
| Elongation | 46% |
Available Diameters & Packaging
| Electrode Diameter | Electrode Length | Package | Harris Item Number |
|---|---|---|---|
| 1/16" | 10" | 5 lb Tube | 308L630 |
| 3/32" | 12" | 10 lb Tube | 308L650 |
| 1/8" | 14" | 10 lb Tube | 308L660 |
| 5/32" | 14" | 10 lb Tube | 308L670 |
Common Applications
Stainless Steel Fabrication
- General stainless steel fabrication
- Type 304 stainless steel components
- Compatible 308-series stainless steels
- Stainless steel equipment
- Shop welding applications
Maintenance & Repair
- Plant maintenance
- Stainless steel equipment repair
- Field repair work
- Brewery equipment
- General stainless steel maintenance welding
Why Choose E308L-16 Stick Electrodes?
Low-Carbon Stainless Filler Metal
The low carbon content of E308L-16 helps increase resistance to intergranular corrosion by reducing carbide precipitation in appropriate stainless steel welding applications.
Versatile Power Source Compatibility
The titania-type coating allows these electrodes to operate with either alternating current or direct current reverse polarity, providing flexibility for shop and field welding equipment.
Product Selection Considerations
Electrode Diameter
Select the electrode diameter appropriate for the base-metal thickness, joint configuration, amperage range, welding position and applicable welding procedure.
Base-Metal Compatibility
Confirm that E308L-16 filler metal is appropriate for the stainless steel grade being welded and complies with the applicable welding procedure, specification, code and project requirements.
Product Resources
View manufacturer product information for Harris E308L-16 stainless steel SMAW / stick welding electrodes.
View Harris Product InformationNeed Help Selecting Harris E308L-16 Stainless Steel Electrodes?
Our welding and industrial supply specialists can help you select the appropriate electrode diameter and package configuration for your stainless steel stick-welding application.
Frequently Asked Questions
What is Harris E308L-16 stainless steel stick electrode?
Harris E308L-16 is a low-carbon stainless steel covered electrode designed for SMAW / stick welding of compatible stainless steels including AISI Types 301, 302, 304, 305 and 308 and corresponding low-carbon grades.
What welding process is used with E308L-16?
E308L-16 is designed for shielded metal arc welding, commonly called SMAW or stick welding.
What is the carbon content of E308L-16?
Harris specifies approximately 0.04% maximum carbon content. The low carbon level helps increase resistance to intergranular corrosion by reducing carbide precipitation.
Can Harris E308L-16 run on AC or DC?
Yes. The titania-type coating is suitable for alternating current or direct current reverse-polarity operation.
What diameters are available?
Available diameters on this GetPipe.com product are 1/16", 3/32", 1/8" and 5/32".
What package sizes are available?
The 1/16" electrode is supplied in a 5 lb tube. The 3/32", 1/8" and 5/32" electrodes are supplied in 10 lb tubes.
What is the tensile strength of E308L-16?
Harris lists an as-welded tensile strength of approximately 84,000 psi.
What specification does E308L-16 meet?
Harris E308L-16 conforms to ANSI/AWS A5.4 and ASME SFA 5.4 E308L-16.
What stainless steels can E308L-16 be used to weld?
Typical compatible base metals include AISI Types 301, 302, 304, 305 and 308 and related low-carbon grades. Always confirm filler-metal compatibility with the applicable welding procedure.
How do I choose the correct variation?
Select the electrode diameter and tube size required for your welding procedure. The selected variation determines the Harris manufacturer part number, package weight, selling price and cost.
Important Ordering Notes
- Select the required electrode diameter and tube size before adding the product to your cart.
- The selected variation determines the Harris manufacturer part number, package weight, selling price and cost.
- The 1/16" electrode is supplied in a 5 lb tube.
- The 3/32", 1/8" and 5/32" electrodes are supplied in 10 lb tubes.
- Electrode length varies by diameter.
- Confirm E308L-16 filler-metal compatibility with the stainless steel base material before welding.
- Verify applicable welding procedure, specification, code and project requirements before use.
- Always follow manufacturer instructions and workplace welding-safety requirements.
