Tube Forgings of America Inc.
Carbon Steel Weld 90° Elbow Long Radius
- SKU:
- DSL9
- Availability:
- Usually Ships Same Day
- Weight:
- 0.00 LBS
Description
Domestic Carbon Steel Weld 90° Elbow Long Radius
Domestic Carbon Steel Weld 90° Long Radius Elbows are manufactured for use in process piping, industrial systems, power generation facilities, oil and gas operations, and commercial piping applications requiring a smooth directional change with minimal flow restriction.
Produced from high-quality carbon steel and manufactured to stringent industry standards, these seamless butt weld fittings provide dependable strength, dimensional accuracy, and long-term performance in demanding service environments.
Key Features
- 90° long radius butt weld elbow design
- Seamless construction for enhanced strength and reliability
- Manufactured from ASTM A/SA234 WPB carbon steel
- Conforms to ANSI B16.9, B16.11, and B16.28 standards through 24"
- Dimensions above 24" conform to MSS-SP-48
- Carbon content not exceeding 0.25% maximum
- Suitable for welding into carbon steel piping systems
- Manufactured in ISO-certified facilities
- Available with Mill Test Reports upon request
- Domestic manufacturing for consistent quality and traceability
Construction Details
These elbows are formed from seamless carbon steel material to provide excellent mechanical strength and a smooth internal flow path. The long radius design helps reduce pressure drop and turbulence compared to short radius alternatives.
Manufacturing processes are carefully controlled to ensure compliance with applicable ASTM, ANSI, and MSS dimensional standards while maintaining consistent wall thickness and weld preparation.
Each fitting is produced in ISO-certified facilities and may be supplied with complete material traceability documentation and Mill Test Reports.
Important Notes
Seamless butt weld fittings conform to ASTM A/SA234 WPB requirements through 24".
Dimensions conform to ANSI B16.9, B16.11, and B16.28 through 24", with larger sizes manufactured to MSS-SP-48 standards.
Review applicable piping specifications, wall thickness requirements, and welding procedures prior to installation.
