316 Stainless Steel 150# Threaded 45° Elbow - SP114
- Availability:
- Usually in Stock – Ships Quickly
- Weight:
- 0.00 LBS
Description
316 Stainless Steel 150# Threaded 45° Elbow - SP114
Charman 316 Stainless Steel SP114 Threaded 45° Elbows provide a directional transition for compatible threaded piping systems where a 45-degree change in direction is required. Manufactured from 316 stainless steel, these fittings are designed for plumbing, industrial, process, maintenance, and general piping applications where corrosion resistance and dependable threaded connections are important.
The SP114 45° Elbow family is available in nominal sizes from 1/4" through 3". Each fitting provides two matching threaded connections arranged at a 45-degree angle for a more gradual directional transition than a standard 90-degree elbow.
Product Highlights
- SP114 45° elbow design
- Two threaded connections
- 316 stainless steel construction
- Nine nominal sizes available
- Designed for 45-degree piping transitions
- Available in sizes ranging from 1/4" through 3"
- Provides a gradual directional change within compatible threaded piping systems
- 316 stainless steel offers enhanced corrosion resistance for suitable service environments
What Is an SP114 Threaded 45° Elbow?
A 316 stainless steel SP114 threaded 45° elbow is a two-opening fitting designed to change the direction of compatible threaded piping by approximately 45 degrees.
The angled configuration provides a more gradual change in direction than a 90° elbow and is useful where piping needs to be routed around equipment, structural components, or other system obstacles.
Why Choose a 316 Stainless Steel SP114 Threaded 45° Elbow?
316 Stainless Steel Construction
- Durable construction
- Enhanced corrosion resistance
- Designed for threaded piping
- Suitable for compatible piping systems
- Useful across industrial and process applications
45-Degree Direction Change
- Angled fitting body
- Two threaded openings
- Gradual directional transition
- Nine nominal sizes available
- Useful where a full right-angle turn is not required
Common Applications
Plumbing & General Piping
- Piping repairs
- Directional changes
- Piping modifications
- Threaded pipe routing
- General-purpose piping installations
Industrial & Process Use
- Equipment piping
- Maintenance work
- Process piping systems
- Industrial piping layouts
- Compatible stainless steel piping installations
Construction Details
316 Stainless Steel Body
- Solid fitting construction
- SP114 elbow configuration
- Designed for directional changes
- Suitable for compatible threaded systems
- 316 stainless steel provides enhanced corrosion resistance for suitable applications
Threaded 45° Elbow Design
- Two-way fitting body
- Two threaded connections
- 45-degree directional transition
- Matching nominal connection sizes
- Both mating connections should be confirmed before installation
Installation & Selection Considerations
- Select the elbow size that matches the piping.
- Confirm both mating threads are compatible before installation.
- Inspect threaded surfaces for damage, debris, or contamination.
- Use a thread-sealing method appropriate for the intended piping system.
- Verify pressure, temperature, media, material, and installation requirements before use.
Review the Charman Inc stainless steel fittings specification sheet for product and dimensional information on the SP114 threaded 45° elbow, or use the complete stainless steel fittings catalog to compare available fitting styles, configurations, and sizes before ordering.
Need Help Selecting a Stainless Steel Pipe Fitting?
Our industrial PVF specialists can help review your pipe size, connection type, stainless steel requirements, application, and installation conditions before you order.
Frequently Asked Questions
What material is the SP114 45° Elbow?
Charman identifies this product family as a 316 stainless steel fitting.
Are these elbows threaded?
Yes. These SP114 45° Elbows are designed for compatible threaded piping connections.
What sizes are available?
This listing includes 1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2", and 3" nominal sizes.
What is a 45° elbow used for?
A 45° elbow changes the direction of compatible threaded piping by approximately 45 degrees.
Which Charman SKUs are included?
The included part numbers are 316181, 316182, 316183, 316184, 316185, 316186, 316187, 316188, and 316190.
How is a 45° elbow different from a 90° elbow?
A 45° elbow provides a more gradual directional change, while a 90° elbow creates a right-angle piping turn.
Where can I review Charman stainless steel fitting information?
The Charman Stainless Steel Fittings Spec Sheet and Complete Catalog are linked directly above.
What should I confirm before ordering?
Confirm nominal size, mating threads, material requirements, pressure, temperature, media, and installation conditions before ordering.
Important Ordering & Installation Notes
- Nine nominal sizes are available.
- Match the elbow to both mating pipe sizes.
- Review the supplied Charman documents for additional fitting information.
- Confirm both thread connections and sealing requirements before installation.
- Verify material, pressure, temperature, media, connection, and installation requirements before service.
