Dixon

3" Aluminum Camlock Type C Coupler x Hose Shank

(No reviews yet) Write a Review
SKU:
NLDIX300-C-AL
Availability:
Limited quantity available.
Weight:
2.00 LBS
*Images are for visual reference only.
  • 3" Aluminum Camlock Type C Coupler x Hose Shank
  • Dixon Logo
$47.00

Represents the combined quantity sold of all the sizes under this product SKU.
Sold:
Frequently bought together:

Description

Dixon NLDIX300-C-AL 3" Aluminum Type C Cam & Groove Coupler x Hose Shank

The Dixon NLDIX300-C-AL 3" Type C Cam & Groove Coupler is a durable aluminum fitting designed to provide a dependable quick-connect connection between compatible camlock systems and hose assemblies.

Manufactured from 356T6 aluminum, this fitting combines a 3" female cam and groove coupler with a 3" hose shank. A Buna-N nitrile gasket, stainless steel cam arm pins with safety clips, and precision-machined construction support reliable connection and sealing performance in compatible liquid transfer systems.

Product Highlights

  • Manufacturer: Dixon Valve & Coupling
  • Model: NLDIX300-C-AL / 300-C-AL
  • 3" Type C cam & groove coupler
  • 3" female camlock coupler x 3" hose shank
  • 356T6 aluminum construction
  • Buna-N nitrile gasket included
  • Maximum working pressure: 125 PSI
  • Precision machined to rigid tolerances
  • Stainless steel cam arm pins
  • Safety clips help secure coupling engagement
  • Long hose shank design
  • Compatible with King Crimp sleeves and ferrules
  • Interchanges with A-A-59326D standard cam and groove fittings
  • Designed for liquid transfer applications
  • Not recommended for compressed air or steam service

Technical Specifications

Manufacturer Dixon Valve & Coupling
Model NLDIX300-C-AL / 300-C-AL
Product Type Cam & Groove Coupler x Hose Shank
Fitting Type Type C
Nominal Size 3"
Connection 1 3" Female Cam & Groove Coupler
Connection 2 3" Hose Shank
Body Material 356T6 Aluminum
Gasket Buna-N Nitrile
Cam Arm Pins Stainless Steel
Cam Arm Retention Safety Clips
Hose Shank Style Long Shank
Maximum Working Pressure 125 PSI
Construction Precision Machined to Rigid Tolerances
Interchange Standard A-A-59326D
Hose Assembly Compatibility King Crimp Sleeves and Ferrules
Intended Service Liquid Transfer Applications
Service Restriction Not Recommended for Compressed Air or Steam Service

Type C Connection Configuration

3" Female Cam & Groove Coupler

The camlock side features a 3" female cam and groove coupler designed to connect with a compatible male cam and groove adapter.

3" Hose Shank

The opposite end features a 3" hose shank designed for attachment to a compatible hose assembly.

356T6 Aluminum Construction

The NLDIX300-C-AL is manufactured from 356T6 aluminum, providing lightweight strength and corrosion resistance for demanding compatible fluid transfer environments.

Buna-N Nitrile Gasket

An included Buna-N nitrile gasket provides sealing at the cam and groove connection. Verify gasket compatibility with the transferred media and operating conditions before installation.

Stainless Steel Cam Arm Pins & Safety Clips

The female coupler uses stainless steel cam arm pins for durability and corrosion resistance. Safety clips help maintain secure cam arm engagement during compatible liquid transfer operations.

Long Hose Shank Design

The fitting features a long hose shank designed for secure hose assembly installation. The supplied product information identifies the shank as compatible with King Crimp sleeves and ferrules.

Maximum Working Pressure

125 PSI

The supplied product information lists a maximum working pressure of 125 PSI. Verify the pressure ratings of the hose, coupling, sleeve or ferrule, and all other system components before operation.

Precision-Machined Construction

The NLDIX300-C-AL is precision machined to rigid tolerances to support proper fitment and reliable sealing with compatible cam and groove components.

A-A-59326D Interchange

The Type C coupler is designed to interchange with compatible cam and groove fittings manufactured to A-A-59326D.

Typical Applications

  • Compatible liquid transfer systems
  • Cam and groove hose assemblies
  • Industrial fluid handling
  • Hose-to-camlock connections
  • Applications using compatible King Crimp sleeves and ferrules

Hose Assembly & Service Notes

This Type C coupler is designed for liquid transfer applications using compatible cam and groove coupling systems.

Verify hose, sleeve, ferrule, gasket, transferred media, and pressure compatibility before installation. The supplied product information states that this fitting is not recommended for compressed air or steam service.

Willy knows his Dixon aluminum Type C cam and groove couplers
Ask Willy: Need Help with the NLDIX300-C-AL Type C Coupler?

Our specialists can help with Type C fitting selection, cam and groove compatibility, hose connections, King Crimp sleeves and ferrules, pressure requirements, and Buna-N gasket compatibility.

Email the GetPipe.com Team Visit Quick Support

Frequently Asked Questions

What is the Dixon NLDIX300-C-AL?

The NLDIX300-C-AL, also identified as 300-C-AL, is a 3" aluminum Type C cam and groove coupler with a female camlock connection on one end and a hose shank on the other.

What are the connection sizes?

The fitting combines a 3" female cam and groove coupler with a 3" hose shank.

What does the female camlock end connect to?

The female cam and groove coupler is designed to connect with a compatible male cam and groove adapter.

What material is the coupler made from?

The body is manufactured from 356T6 aluminum.

What gasket is included?

The supplied product information identifies an included Buna-N nitrile gasket.

What is the maximum working pressure?

The supplied product information lists a maximum working pressure of 125 PSI.

What material are the cam arm pins?

The cam arm pins are made from stainless steel and are equipped with safety clips.

Can this Type C coupler be used with King Crimp components?

Yes. The supplied product information states that the long hose shank is compatible with King Crimp sleeves and ferrules.

Does this coupler interchange with standard camlock fittings?

The supplied product information states that it interchanges with compatible cam and groove fittings manufactured to A-A-59326D.

Can this fitting be used for compressed air or steam?

No. The supplied product information states that the fitting is designed for liquid transfer applications and is not recommended for compressed air or steam service.

Important Ordering & Product Notes

  • This listing covers the Dixon NLDIX300-C-AL / 300-C-AL 3" Aluminum Type C Cam & Groove Coupler x Hose Shank.
  • Fitting type is Type C.
  • Connection configuration is 3" female cam & groove coupler x 3" hose shank.
  • Body material is 356T6 aluminum.
  • A Buna-N nitrile gasket is included.
  • Cam arm pins are stainless steel and include safety clips.
  • Maximum working pressure is listed as 125 PSI.
  • Long hose shank is identified as compatible with King Crimp sleeves and ferrules.
  • Designed to interchange with compatible A-A-59326D cam and groove fittings.
  • Designed for liquid transfer applications.
  • Specific product dimensions, product weight, and temperature range were not supplied in the provided product information.
  • Verify hose, sleeve, ferrule, gasket, media, and pressure compatibility before installation.
  • Not recommended for compressed air or steam service.
