1" x 1/2" Schedule 80 CPVC 90° Elbow (SOC x FPT) Bushed
- SKU:
- 807-130C
- Availability:
- Usually Ships Same Day
- Weight:
- 0.27 LBS
Description
1" x 1/2" Schedule 80 CPVC 90° Elbow (SOC x FPT) Bushed
1" x 1/2" Schedule 80 CPVC 90° Elbow (SOC x FPT) Bushed provides a 90-degree direction change while reducing from a 1" socket connection to a 1/2" Female Pipe Thread connection. The bushed configuration combines size reduction, directional change, and connection transition within one fitting.
The 1" x 1/2" Schedule 80 CPVC bushed elbow connects compatible 1" CPVC pipe to a 1/2" male-threaded component. Selection should account for both nominal sizes, socket compatibility, male-thread compatibility, elbow orientation, system requirements, and proper CPVC installation procedures.
Product Highlights
- CPVC construction
- Schedule 80 design
- 1" x 1/2" sizing
- Bushed elbow configuration
- 1" socket connection
- 1/2" Female Pipe Thread connection
- Provides a 90° reducing direction change
- Combines size reduction and connection transition
Technical Specifications
| Product Type | Bushed 90° Elbow |
|---|---|
| Material | CPVC |
| Schedule | Schedule 80 |
| Nominal Size | 1" x 1/2" |
| Configuration | Reducing Bushed 90° Elbow |
| Connection | Socket (SOC) x Female Pipe Thread (FPT) |
| Socket Connection | 1" |
| Threaded Connection | 1/2" Female Pipe Thread |
| Direction Change | 90° |
| Primary Function | Provide a 90° Reduction from 1" CPVC Pipe to a 1/2" Male-Threaded Component |
Bushed Elbow Design
The bushed elbow design incorporates a reduced threaded connection directly into the 90-degree fitting. This allows the elbow to transition from the larger 1" socket side to the smaller 1/2" female-threaded side without requiring a separate reducing bushing.
Both nominal connection sizes should be confirmed before ordering. Proper elbow orientation should also be established before the socket connection is solvent cemented.
1" Socket Connection
The 1" socket connection is designed to accept appropriately sized compatible CPVC pipe. This end integrates the elbow into the Schedule 80 CPVC piping system using a solvent-cement joint.
The pipe end and fitting socket should be clean and properly prepared before assembly. Compatible CPVC primer, solvent cement, insertion procedures, and required cure times should be followed.
1/2" Female Threaded Connection
The 1/2" Female Pipe Thread connection accepts an appropriately sized compatible male-threaded component. This reduced threaded outlet provides the connection transition at the opposite side of the elbow.
Thread compatibility should be confirmed before assembly. Appropriate threaded plastic-piping procedures should be used while avoiding excessive tightening that could place unnecessary stress on the CPVC fitting.
Reducing 90° Transition
A 1" x 1/2" Schedule 80 CPVC Bushed 90° Elbow combines three functions within one fitting: a right-angle direction change, a size reduction, and a socket-to-thread transition. This can simplify piping arrangements that would otherwise require multiple separate fittings.
System temperature, pressure, fluid compatibility, joining requirements, and applicable installation standards should be reviewed for the intended application. Proper piping alignment and support should be maintained around both connections.
Installation & Selection Considerations
- Confirm the 1" socket size.
- Confirm the 1/2" FPT size.
- Verify the bushed configuration.
- Check elbow orientation before joining.
- Avoid excessive threaded tightening.
Our piping specialists can help review the 1" socket size, 1/2" female-thread size, bushed configuration, CPVC compatibility, and installation considerations before you order.
Frequently Asked Questions
What is a 1" x 1/2" Schedule 80 CPVC Bushed 90° Elbow used for?
It provides a 90-degree direction change while reducing from a 1" CPVC socket connection to a 1/2" female-threaded connection.
What does bushed mean on this elbow?
Bushed identifies the integrated reduced threaded connection that transitions from the larger socket size to the smaller threaded size.
What does SOC x FPT mean?
SOC x FPT means the fitting has one socket connection and one Female Pipe Thread connection.
What connects to the 1/2" FPT end?
The 1/2" Female Pipe Thread end accepts an appropriately sized compatible male-threaded component.
How is the 1" socket connection installed?
The 1" socket is designed for compatible CPVC solvent-cement joining using appropriate preparation and installation procedures.
What should I confirm before ordering?
Confirm the 1" x 1/2" size, SOC x FPT configuration, bushed design, mating male thread, and required elbow orientation.
