Description
Schedule 80 CPVC 90° Elbow (SOC x FPT)
Schedule 80 CPVC 90° Elbow (SOC x FPT) provides a 90-degree direction change while transitioning between a CPVC socket connection and a Female Pipe Thread connection. The mixed connection configuration allows compatible CPVC pipe and a male-threaded component to connect through one elbow.
The Schedule 80 CPVC SOC x FPT 90° elbow combines solvent-cement and threaded connection methods in a compact directional fitting. Selection should account for nominal size, socket compatibility, male-thread compatibility, elbow orientation, system requirements, and proper CPVC installation procedures.
Product Highlights
- CPVC construction
- Schedule 80 design
- 90° elbow configuration
- Socket connection interface
- Female Pipe Thread connection
- Provides a 90° direction change
- Combines solvent-cement and threaded connections
- Designed for compatible Schedule 80 CPVC piping
Technical Specifications
| Product Type | 90° Elbow |
|---|---|
| Material | CPVC |
| Schedule | Schedule 80 |
| Configuration | 90° Mixed-Connection Elbow |
| Connection | Socket (SOC) x Female Pipe Thread (FPT) |
| Socket Interface | Compatible CPVC Pipe |
| Thread Interface | Compatible Male Pipe Thread |
| Direction Change | 90° |
| Joining Method | CPVC Solvent-Cement x Threaded Connection |
| Primary Function | Provide a 90° Transition Between CPVC Pipe and a Male-Threaded Component |
90° Elbow Design
The 90° elbow design provides a right-angle direction change while also transitioning between two different connection methods. One end accepts compatible CPVC pipe while the opposite end provides a female-threaded interface.
The fitting should be oriented correctly before the socket connection is solvent cemented. Nominal size and thread compatibility should also be verified before installation begins.
Socket Connection
The socket connection is designed to accept appropriately sized compatible CPVC pipe. This end is joined using suitable CPVC solvent-cement procedures to integrate the elbow into the piping system.
The pipe end and fitting socket should be clean and properly prepared before assembly. Compatible CPVC primer, solvent cement, insertion procedures, and required cure times should be followed.
Female Threaded Connection
The Female Pipe Thread connection accepts an appropriately sized compatible male-threaded component. This creates a threaded transition at the opposite end of the 90-degree directional change.
Thread compatibility should be confirmed before assembly. Appropriate threaded plastic-piping procedures should be used while avoiding excessive tightening that could place unnecessary stress on the CPVC fitting.
Schedule 80 CPVC Application
A Schedule 80 CPVC 90° Elbow SOC x FPT provides both a directional change and a connection transition in one fitting. This can reduce the need for a separate threaded adapter immediately adjacent to the elbow.
System temperature, pressure, fluid compatibility, joining requirements, and applicable installation standards should be reviewed for the intended application. Proper support should be maintained around both connections.
Installation & Selection Considerations
- Confirm the nominal size.
- Verify SOC x FPT configuration.
- Confirm male-thread compatibility.
- Check elbow orientation before joining.
- Avoid excessive threaded tightening.
Our piping specialists can help review nominal size, socket compatibility, male-thread compatibility, elbow orientation, CPVC requirements, and installation considerations before you order.
Frequently Asked Questions
What is a Schedule 80 CPVC SOC x FPT 90° Elbow used for?
It provides a 90-degree direction change while transitioning between compatible CPVC pipe and a male-threaded component.
What does SOC x FPT mean?
SOC x FPT means the elbow has one socket connection and one Female Pipe Thread connection.
What connects to the FPT end?
The Female Pipe Thread end accepts an appropriately sized compatible male-threaded component.
How is the socket end installed?
The socket connection is designed for compatible CPVC solvent-cement joining using appropriate preparation and installation procedures.
How should the threaded connection be installed?
Use appropriate threaded plastic-piping procedures and compatible sealing materials while avoiding excessive tightening.
What should I confirm before ordering?
Confirm nominal size, SOC x FPT configuration, male-thread compatibility, Schedule 80 CPVC requirements, and elbow orientation.
Important Ordering & Installation Notes
- Confirm the nominal size.
- Verify SOC x FPT configuration.
- Confirm male-thread compatibility.
- Check orientation before installation.
- Avoid excessive tightening of CPVC threads.
