TPI Corporation
High Velocity Air Circulators - HHV30-120V
- SKU:
- HHV30-120V
- Availability:
- Lead time varies. We will confirm ship date after order. Need exact lead time? Add to quote.
- Weight:
- 85.00 LBS
- Description:
- 30" 1 HP 746 Watts"
- Volts:
- 120
- Phase:
- 1
- CFM/RPM:
- 14250/1700
- SizeH x W x D:
- 38-7/8 x 38-7/8 x 16
- Amps:
- 10.0
Description
High Velocity Air Circulators - HHV30-120V
All steel construction.Fully enclosed motor.18", 24" & 30" model sizes.Heavy-duty yoke mounted fan head.Great for use in warehouses and loading dock areas.Housing designed for all types of air circulating applications to provide directional - high velocity air flow. Built-in rotating design allows the supplied mounting bracket to pivot 120 degrees in (9) adjustment setting at 15 degree variations. Front and rear spiral wound grills are OSHA approved and have a black coated finish. All units are shipped fully assembled and ready for hard-wired connections. TEAO motor has a Class B rating, with automatic thermal protection and ball bearing design for harsh environments; rated up to 115 degrees Fahrenheit maximum ambient temperature. Single and three phase options available in 120, 208/240, 277 and 480-volt. Mounting brackets sold separately. FOB Shipping Point. See Related Items tab for High Velocity Air Circulators - Mounting Brackets.
