150# Galvanized Malleable Hex Bushings
- SKU:
- SGHB
- Availability:
- Usually Ships Same Day
- Weight:
- 0.00 LBS
Description
150# Galvanized Malleable Iron Hex Bushing
150# Galvanized Malleable Iron Hex Bushings are designed to reduce threaded pipe size within a compact fitting while providing a secure male-to-female NPT connection.
Manufactured from durable malleable iron with a hot-dip galvanized finish, these Class 150 bushings provide dependable strength and added corrosion resistance for industrial, commercial, plumbing, HVAC, water, and outdoor piping applications.
Product Highlights
- Compact threaded reducing bushing
- Male NPT outside x female NPT inside
- Reduces pipe size directly within a threaded fitting
- Hex head provides wrench flats for installation and removal
- Helps minimize overall fitting length compared with multi-piece reductions
- Hot-dip galvanized finish for added corrosion resistance
- Durable malleable iron construction
- Class 150 fitting
- Malleable castings conform to ASTM A197
- Hot-dipped galvanized fittings conform to ASTM A153
- Malleable bushings conform to ASME B16.14
- NPT threads conform to ASME B1.20.1
- Class 150 fittings are UL Listed and FM Approved at 300 PSI
- Galvanized fittings meet ANSI/NSF 61-4 Annex G and CA AB1953 (<0.25% lead)
- Manufactured in an ISO-certified facility
- Country of origin: Thailand & China
Technical Specifications
| Product Type | Hex Bushing |
|---|---|
| Material | Malleable Iron |
| Finish | Hot-Dip Galvanized |
| Pressure Class | 150# |
| Connection Type | Male NPT x Female NPT |
| Configuration | Reducing Bushing |
| Installation Feature | Hex Head / Wrench Flats |
| Primary Function | Reduce Threaded Pipe Size |
| Casting Standard | ASTM A197 |
| Galvanizing Standard | ASTM A153 |
| Bushing Standard | ASME B16.14 |
| Thread Standard | ASME B1.20.1 |
| Listings / Approvals | UL Listed & FM Approved at 300 PSI |
| Lead / Potable Water Compliance | ANSI/NSF 61-4 Annex G and CA AB1953 (<0.25% lead) |
| Manufacturing | ISO-Certified Facility |
| Country of Origin | Thailand & China |
Construction & Applications
Malleable Iron Construction
Manufactured from malleable iron castings conforming to ASTM A197 for dependable strength and durability in threaded piping installations.
Male x Female Reduction
The larger outside connection uses male NPT threads while the smaller inside connection uses female NPT threads, allowing a smaller pipe or fitting to connect directly into a larger threaded opening.
Hot-Dip Galvanized Finish
The galvanized coating conforms to ASTM A153 and provides added protection against rust and corrosion in moisture-prone and outdoor environments.
Why Use a Hex Bushing?
Compact Size Reduction
A hex bushing provides pipe-size reduction within a very short fitting length, making it useful where installation space is limited.
Easy Wrench Installation
The hex-shaped head provides flat surfaces for wrench engagement, helping simplify tightening and removal during installation or maintenance.
Typical Applications
Commercial & Mechanical Piping
- Commercial plumbing systems
- HVAC piping
- Mechanical piping
- Water distribution
- Equipment connections
- Threaded size transitions
Galvanized Applications
- Outdoor piping
- Moist environments
- Water-service applications
- Industrial installations
- General galvanized piping systems
Need a Smaller Bushing?
For smaller size combinations, see our selection of Merchant Steel Bushings.
Ask Willy: Need Pipe Size Help?
Use our common pipe diameters and wall thickness chart to confirm both the male and female connection sizes before ordering galvanized malleable iron bushings. You can also review the hex bushing specification sheet and Certificate of Conformance below.
Standards & Approvals
ASTM Standards
Malleable iron castings conform to ASTM A197, while hot-dipped galvanized fittings conform to ASTM A153.
ASME Standards
Malleable bushings conform to ASME B16.14, while NPT threads conform to ASME B1.20.1.
UL, FM & Lead Compliance
Class 150 fittings are UL Listed and FM Approved at 300 PSI. Galvanized fittings meet ANSI/NSF 61-4 Annex G and CA AB1953 requirements listed in the supplied product information.
Related Malleable Iron Standards
- Malleable fitting dimensions conform to ASME B16.3 where applicable.
- Malleable bushings, plugs, and locknuts conform to ASME B16.14.
- Malleable unions conform to ASME B16.39.
- Class 300 fittings are UL Listed according to the supplied product information.
- NPT threads on applicable fittings conform to ASME B1.20.1.
Need More Galvanized Malleable Iron Fittings?
Shop our complete selection of 150# galvanized malleable iron fittings, including hex bushings, elbows, tees, couplings, unions, caps, plugs, and other threaded fittings.
Frequently Asked Questions
What is a hex bushing used for?
A hex bushing is used to reduce a larger female-threaded connection to a smaller female connection in a compact threaded fitting.
Which side of a hex bushing is male?
The outside, larger-diameter threads are male NPT. The smaller internal threads are female NPT.
Why does the bushing have a hex head?
The hex shape provides wrench flats that make the fitting easier to tighten or remove during installation and maintenance.
How is a hex bushing different from a reducing coupling?
A reducing coupling has female threads at both ends. A hex bushing has male threads on the outside and female threads on the inside, allowing it to screw directly into another female-threaded fitting.
Can a hex bushing save installation space?
Yes. Its compact male-to-female design can provide a shorter pipe-size transition than assemblies using multiple fittings.
What standard applies specifically to malleable iron bushings?
The supplied product information states that malleable bushings, plugs, and locknuts conform to ASME B16.14.
What standard applies to the galvanized coating?
Hot-dipped galvanized fittings conform to ASTM A153 according to the supplied product information.
What thread standard applies?
NPT threads conform to ASME B1.20.1.
Is this fitting UL Listed and FM Approved?
The supplied product information states that Class 150 fittings are UL Listed and FM Approved at 300 PSI.
What sizes should I verify before ordering?
Confirm both the larger male NPT size and the smaller female NPT size to ensure the bushing matches the intended reduction.
Important Ordering & Installation Notes
- Confirm both the larger male NPT size and smaller female NPT size before ordering.
- The outside connection is male NPT and the internal connection is female NPT.
- Use the hex wrench flats for installation rather than gripping threaded surfaces whenever practical.
- Malleable bushings conform to ASME B16.14 according to the supplied product information.
- NPT threads conform to ASME B1.20.1.
- Hot-dipped galvanized fittings conform to ASTM A153.
- Use compatible galvanized pipe, fittings, thread sealant, and accepted threaded installation practices.
- Avoid damaging the galvanized coating during handling and installation.
- Verify system pressure, service, potable-water, code, and approval requirements before installation.
- Refer to the specification sheet and Certificate of Conformance for additional product information.
