Lesso America
ABS DWV Coupling (HUB x HUB)
- SKU:
- LN100
- Availability:
- Usually Ships Same Day
- Weight:
- 0.00 LBS
Description
ABS DWV Coupling (HUB x HUB)
ABS DWV Couplings provide a dependable way to join two compatible lengths of ABS pipe in sanitary drain, waste, vent, sewer, and general drainage systems.
Featuring hub connections on both ends, this non-pressure fitting is designed for solvent-cement installation with compatible ABS DWV pipe. Manufactured for long-term service in drainage applications, it meets recognized ABS DWV standards including ASTM D2661, CSA B181.1, and NSF Standard 14.
Product Highlights
- ABS DWV coupling fitting
- Hub x Hub connection configuration
- Joins two compatible lengths of ABS pipe
- Designed for drain, waste, and vent systems
- Suitable for sewer and general drainage applications
- Non-pressure fitting
- Solvent-cement installation
- Maximum operating temperature of 140°F
- Not intended for compressed air or gas service
- Not intended for pressure testing
- Manufactured from virgin ABS polymers
- Complies with ASTM D2661
- Certified to CSA B181.1
- Meets NSF Standard 14 requirements
Technical Specifications
| Product Type | ABS DWV Coupling |
|---|---|
| Material | ABS |
| Connection Type | Hub x Hub |
| Joint Method | Solvent Cement |
| System Type | Drain, Waste, and Vent (DWV) |
| Pressure Service | Non-Pressure |
| Maximum Operating Temperature | 140°F |
| Primary Function | Join Two Compatible Lengths of ABS DWV Pipe |
| Referenced Standards | ASTM D3965, ASTM D2661, CSA B181.1, NSF Standard 14 |
| Typical Applications | Sanitary Drainage, Waste Lines, Vent Systems, Sewer, and General Drainage |
Connection Configuration
First Hub Connection
The first hub accepts compatible ABS DWV pipe for a permanent solvent-cement connection.
Second Hub Connection
The opposite hub accepts another compatible length of ABS DWV pipe, creating a straight in-line connection between the two pipe sections.
Construction Details
The coupling is manufactured from virgin ABS polymer material suitable for molded fittings and ABS drainage systems.
The dual-hub configuration allows two compatible pipe sections to be joined in a straight run using approved ABS solvent cement.
Its one-piece design provides a simple, compact connection for non-pressure sanitary drainage, waste, vent, sewer, and general drainage installations.
Why Choose an ABS DWV Coupling?
Straight Pipe Connection
- Joins two ABS pipe sections
- Hub connection on both ends
- Simple in-line configuration
- Permanent solvent-cement joint
- Useful for extensions, repairs, and new installations
ABS DWV Benefits
- Lightweight construction
- Easy handling and installation
- Suitable for non-pressure drainage systems
- Compatible with ABS DWV piping systems
- Designed for long-term drainage service
Typical Applications
Drainage Systems
- Sanitary drain lines
- Waste piping
- Vent piping
- Sewer connections
- General building drainage
Installation Uses
- Joining pipe sections
- Extending existing ABS piping
- Repairing compatible DWV runs
- Residential plumbing
- Commercial drainage systems
Standards & Compliance
- ASTM D3965: ABS material requirements for pipe extrusion and molded fittings
- ASTM D2661: Schedule 40 ABS drain, waste, and vent pipe and fittings
- CSA B181.1: ABS drain, waste, and vent pipe, fittings, and accessories
- NSF Standard 14: Plastic piping system components and related materials
Installation
Verify the nominal hub size before installation and confirm compatibility with the intended ABS DWV pipe.
Cut the pipe square and remove burrs from each pipe end. Clean and prepare the pipe and hub surfaces according to accepted ABS solvent-cement installation procedures.
Apply compatible ABS solvent cement as required, then fully seat each pipe into the appropriate hub while maintaining proper alignment.
Allow completed joints to cure according to the solvent cement manufacturer's recommendations before placing the drainage system into service.
Our piping specialists can help review your pipe size, application, installation requirements, and ABS DWV compatibility before you order.
Email the GetPipe.com Team Visit Quick SupportFrequently Asked Questions
What is an ABS DWV coupling used for?
It is used to join two compatible lengths of ABS pipe in drain, waste, vent, sewer, and general drainage systems.
What does HUB x HUB mean?
It means both ends are hub connections designed to accept compatible ABS pipe for solvent-cement installation.
Is this fitting intended for pressure systems?
No. This fitting is designed for non-pressure drain, waste, vent, sewer, and drainage applications.
Can it be used for compressed air or gas?
No. The supplied product information specifically states that it is not intended for transporting compressed air or gas.
Can this fitting be used for pressure testing?
No. The supplied product information states that it should not be used for pressure testing.
What is the maximum operating temperature?
The supplied product information specifies applications where operating temperatures do not exceed 140°F.
What installation method is used?
The hub connections are installed using compatible ABS solvent cement according to accepted installation procedures.
What standards are referenced?
The supplied product information references ASTM D3965, ASTM D2661, CSA B181.1, and NSF Standard 14.
Are chemical compatibility considerations important?
Yes. Installations should be protected from incompatible chemicals, fire-stopping materials, thread sealants, or other substances that may damage ABS compounds.
What should I verify before ordering?
Confirm the nominal hub size, mating ABS pipe size, application type, operating temperature, and compatibility with the intended installation environment.
Important Ordering & Installation Notes
- This listing is for an ABS DWV Coupling with HUB x HUB connections.
- Verify the required nominal pipe size before ordering.
- Both ends are hub connections designed to accept compatible ABS pipe.
- This fitting is intended for non-pressure DWV, sewer, and general drainage applications.
- Do not use for compressed air or gas service.
- Do not use for pressure testing.
- Maximum operating temperature is 140°F.
- Use compatible ABS solvent cement for installation.
- Cut pipe square and remove burrs before assembly.
- Clean and prepare all mating surfaces before solvent-cement installation.
- Fully seat each pipe into the corresponding hub.
- Allow completed joints to cure according to the solvent cement manufacturer's recommendations before service.
- Protect the fitting from incompatible chemicals and materials that may damage ABS compounds.
- Use caution with fire-stopping materials, sealants, and chemicals used around ABS piping.
- Consult manufacturer documentation for complete dimensions and installation requirements.
- Follow applicable plumbing codes and manufacturer installation recommendations.
