ABS DWV Closet Flange (MIPT)
- SKU:
- LN831
- Availability:
- Usually Ships Same Day
- Weight:
- 0.00 LBS
Description
ABS DWV Closet Flange (MIPT)
ABS DWV Closet Flanges provide a secure connection point between a toilet and the drain, waste, and vent system while anchoring the fixture at the finished floor.
Featuring a Male Iron Pipe Thread (MIPT) connection, this flange is designed to thread into a compatible female-threaded ABS DWV fitting or pipe connection. Its flange body provides the mounting surface needed for closet bolts and toilet installation while maintaining a dependable connection to the sanitary drainage system. Manufactured for ABS DWV service, it meets recognized standards including ASTM D2661, CSA B181.1, and NSF Standard 14.
Product Highlights
- ABS DWV closet flange
- Male Iron Pipe Thread (MIPT) connection
- Designed for toilet and water closet installations
- Connects fixture outlet to the ABS DWV drainage system
- Provides a mounting surface for securing the toilet
- Threaded connection fits compatible female-threaded components
- Designed for sanitary drain, waste, and vent systems
- Non-pressure fitting
- Maximum operating temperature of 140°F
- Not intended for compressed air or gas service
- Not intended for pressure testing
- Manufactured from virgin ABS polymers
- Complies with ASTM D2661
- Certified to CSA B181.1
- Meets NSF Standard 14 requirements
Technical Specifications
| Product Type | ABS DWV Closet Flange |
|---|---|
| Material | ABS |
| Connection Type | Male Iron Pipe Thread (MIPT) |
| Joint Method | Threaded |
| Fixture Type | Toilet / Water Closet |
| System Type | Drain, Waste, and Vent (DWV) |
| Pressure Service | Non-Pressure |
| Maximum Operating Temperature | 140°F |
| Primary Function | Connect and Secure a Toilet to an ABS DWV Drainage System |
| Referenced Standards | ASTM D3965, ASTM D2661, CSA B181.1, NSF Standard 14 |
| Typical Applications | Residential and Commercial Toilet Installations, Sanitary Drainage, and ABS DWV Systems |
Connection Configuration
MIPT Connection
The male-threaded connection is designed to thread into a compatible female-threaded ABS DWV fitting or pipe connection.
Closet Flange Body
The flange body provides the mounting interface for the toilet and accommodates the closet bolts used to secure the fixture at the floor.
Closet Flange Design
The closet flange serves as the transition between the toilet outlet and the sanitary drainage piping below the floor.
Its male-threaded connection provides a mechanical attachment to a compatible female-threaded ABS DWV component, while the flange surface supports proper positioning and fastening of the toilet.
A separate toilet sealing component, such as the appropriate wax ring or approved alternative seal, is typically installed between the toilet outlet and flange as part of the complete fixture installation.
Why Choose an ABS DWV Closet Flange?
Fixture Connection
- Provides a dedicated toilet connection point
- Supports closet bolt installation
- Connects fixture outlet to DWV piping
- Threaded connection allows mechanical attachment
- Designed for sanitary drainage systems
ABS DWV Benefits
- Lightweight construction
- Easy handling during installation
- Suitable for non-pressure drainage systems
- Compatible with ABS DWV components
- Designed for long-term sanitary drainage service
Typical Applications
Fixture Installations
- Residential toilets
- Commercial toilets
- Water closets
- Bathroom renovations
- New construction plumbing
Drainage Systems
- Sanitary drain lines
- ABS DWV systems
- Waste piping
- Residential plumbing
- Commercial sanitary drainage
Standards & Compliance
- ASTM D3965: ABS material requirements for pipe extrusion and molded fittings
- ASTM D2661: Schedule 40 ABS drain, waste, and vent pipe and fittings
- CSA B181.1: ABS drain, waste, and vent pipe, fittings, and accessories
- NSF Standard 14: Plastic piping system components and related materials
Installation
Verify the required MIPT size and confirm compatibility with the intended female-threaded ABS DWV connection before installation.
Inspect the mating threads and make sure they are clean, undamaged, and properly aligned before threading the flange into position.
Install the flange at the proper finished-floor height and orientation so the closet bolt slots align correctly with the toilet base.
If thread sealant is required, use only a product confirmed compatible with ABS. Avoid incompatible compounds that could damage the fitting.
Install the appropriate toilet seal and closet bolts according to the toilet manufacturer's instructions and applicable plumbing codes.
Our piping specialists can help review your thread size, toilet connection, finished-floor setup, and ABS DWV compatibility before you order.
Email the GetPipe.com Team Visit Quick SupportFrequently Asked Questions
What is an ABS DWV closet flange used for?
It is used to connect and secure a toilet or water closet to an ABS drain, waste, and vent system.
What does MIPT mean?
MIPT means Male Iron Pipe Thread. The flange is designed to thread into a compatible female-threaded pipe or fitting.
Does the closet flange hold the toilet in place?
Yes. The flange provides the mounting surface for closet bolts that help secure the toilet to the floor.
Does this flange provide the toilet-to-flange seal by itself?
No. The toilet installation normally requires a separate compatible sealing component, such as a wax ring or approved alternative seal.
Is this fitting intended for pressure systems?
No. This fitting is intended for non-pressure sanitary drain, waste, and vent applications.
Can it be used for compressed air or gas?
No. The supplied product information specifically states that ABS DWV fittings are not intended for transporting compressed air or gas.
Can this fitting be used for pressure testing?
No. The supplied product information states that ABS DWV fittings should not be used for pressure testing.
What is the maximum operating temperature?
The supplied product information specifies applications where operating temperatures do not exceed 140°F.
What standards are referenced?
The supplied product information references ASTM D3965, ASTM D2661, CSA B181.1, and NSF Standard 14.
What should I verify before ordering?
Confirm the MIPT connection size, mating female-threaded component, toilet installation requirements, finished-floor configuration, and intended ABS DWV application.
Important Ordering & Installation Notes
- This listing is for an ABS DWV Closet Flange with an MIPT connection.
- Verify the required nominal thread size before ordering.
- The MIPT connection threads into a compatible female-threaded ABS DWV component.
- Verify flange height relative to the finished floor before installation.
- Confirm closet bolt slot orientation before final tightening.
- A separate compatible toilet seal is typically required.
- This fitting is intended for non-pressure sanitary DWV applications.
- Do not use for compressed air or gas service.
- Do not use for pressure testing.
- Maximum operating temperature is 140°F.
- Inspect all mating threads before assembly.
- Start threaded connections carefully to help prevent cross-threading.
- Do not overtighten ABS threaded components.
- Use only thread-sealing materials confirmed compatible with ABS if required.
- Avoid incompatible chemicals, aggressive sealants, and fire-stopping materials that may damage ABS compounds.
- Secure the toilet using appropriate closet bolts and hardware.
- Follow the toilet manufacturer's installation instructions.
- Consult manufacturer documentation for complete dimensions and installation requirements.
- Follow applicable plumbing codes and manufacturer recommendations.
