150# Galvanized Service Tee

The hot-dipped zinc galvanized finish provides enhanced corrosion resistance for plumbing, mechanical, fire protection, and industrial applications. Manufactured to meet recognized ASME and ASTM standards, these threaded service tees deliver dependable performance and compatibility with standard NPT threaded pipe systems.

Key Features

• Class 150 galvanized malleable iron service tee
• Hot-dipped zinc galvanized finish for corrosion resistance
• Female NPT threaded connections
• Manufactured to ASME B16.3 dimensions
• Threads conform to ASME B1.20.1
• Material manufactured to ASTM A197 and ASTM A153 requirements
• Figure 3106 design
• Available in sizes from 1/4" through 2"

Construction Details

Constructed from durable malleable iron and finished with a hot-dipped zinc galvanized coating to help resist rust and corrosion in demanding environments.

Precision-machined female NPT threads provide reliable engagement with compatible threaded pipe and fittings for secure branch connections.

Specifications

• Figure Number: 3106
• Product Type: Service Tee
• Pressure Class: 150
• Material: Malleable Iron
• Finish: Hot-Dipped Zinc Galvanized
• Series: 34AC

Important Notes

Manufactured in accordance with ASME B16.3, ASTM A197, ASTM A153, and ASME B1.20.1 standards.

Compatible with standard NPT threaded piping systems.

Select the appropriate nominal pipe size from the available options when ordering.
