Valves

Lead Free Bronze Ball Valve, 2 Piece, Full Port, Threaded Connection, Stainless Steel Trim, Extended Handle, 600 CWP, 150 WSP Dezincification Resistant Lead Free Bronze Blow-Out Proof Stem Heavy Commercial Pattern 100% Leak Tested IAPMO Certified:...

Lead Free Bronze Ball Valve, 2 Piece, Full Port, Threaded Connection, Stainless Steel Trim, Insulated Handle, 600 CWP, 150 WSP Dezincification Resistant Lead Free Bronze Blow-Out Proof Stem Heavy Commercial Pattern 100% Leak Tested IAPMO Certified:...

Lead Free Bronze Ball Valve, 2 Piece, Full Port, Threaded Connection, Stainless Steel Trim, Locking Handle, 600 CWP, 150 WSP Dezincification Resistant Lead Free Bronze Blow-Out Proof Stem Heavy Commercial Pattern 100% Leak Tested IAPMO Certified:...

Lead Free In-Line Spring Check Valve (C x C) Dezincification Resistant (DZR) Lead Free Brass Material Solder-Joint conform ASME B16.22 Forged Brass body Sealed In EPDM-Rubber Spring Made In Stainless Steel AISI 304 Screw Made in Brass Product Spec Sheet...

Series 500BBG Lug Style Butterfly Valve Gear Operator DI Body Aluminum Bronze Disc BUNA Seat Spec Sheet PDF Pipe Chart: Common Diameters & Wall Thicknesses PDF Certificate of Conformance PDF

Grooved Butterfly Valve - Gear Operated 300 psi working pressure EPDM 200° F maximum working temperature NBR 180° F maximum working temperature Gear Operator Grease fitting on gear operator Grooved Catalog PDF Grooved Cross Reference PDF

Mini Ball Valves Nickel Plated Brass Standard Port Blow-out proof stem PTFE seats and FKM stem seal Max Temperature: 330°F (166°C) Pressure Rating 450 PSI Canadian Standard Association approved Catalog Page 880 PDF

Model N Homestead Handle Wrench Handle Only for the Homestead Lubricated Plug Valve Wrench Size N Fits 5"- 8" Model #612 Downloads: Series 600 Lubricated Plug Valve Brochure (See page 24) PDF Series 600 Lubricated Plug Valve IOM Manual PDF Series 600...

Seal Welded 3-Way Ball Valve Stainless Steel Seal Welded Construction for Safety Reduced Port Body: Stainless Steel Ball & Stem: Stainless Steel Seat: 316 Stainless Steel Seal: Graphite Handle: Stainless Latch Lock 2160WOG Rating on CF8M, 2220WOG on...

Sanitary 3-Piece Ball Valve Full Port Clamp End Sharpe® polymer-seated, high-purity 3-piece ball valves provide superior performance and reliability in a wide range of high purity applications. Bi-directional, bubble tight shut-off Pressure Rating:...

Sanitary In-Line Sight Glass Pyrex - Clamp End Clamp sight glass allows for the ability to visually inspect tube media. Clamp connection requires use of gaskets and clamp for secure fit. Available for tube outside diameter connections up to 4". T316 /...

316/L Stainless Steel Sanitary Sight Glass Clamp End Sanitary tubing and fittings are produced to 3-A Sanitary Standards Stainless steel sanitary tubing dimensions and materials conform to ASTM A269/A270 Independent lab verification that fittings meet...

Sanitary Tube Full Port Butterfly Valve Clamp End Bi-directional, bubble tight shut-off Pressure Rating: 150 PSI CWP Body Material: 304 Stainless Steel Operating Temperature: 200° F (93C) maximum Seat Material EPDM Manufacturing facility is ISO...

Seal Welded, 1000 PSI, Stainless Steel Ball Valve One Piece - Seal Welded Construction All sizes are Full Port 1000 PSI CWP Rating 150 PSIG Saturated Steam Rating All Models are NACE MR-01-75 Compliant CF8M Bodies and Tailpieces, 316 Stainless Steel...

Series 25116 & 25316 - Stainless Steel Flanged Check Valves Sharpe® metal-seated, stainless steel, flanged swing check valves provide superior performance and reliability in a wide range of applications. Uni-directional shut-off Pressure Class:...

Series 34836 - Stainless Steel Forged Gate Valves Sharpe® metal-seated, forged steel, gate valves provide superior performance and reliability in a wide range of applications. Outside Screw and Yoke (OS&Y) - Rising Stem Design Bi-directional...

Series 39034 - Carbon Steel Ball Valve Three Piece Design Sharpe® economy, polymer-seated, 3-piece ball valves provide a lower cost solution in many applications. Full Port 1000 CWP Carbon Steel ASTM A216 WCB Threaded or Socket Weld Ends Blow-Out...

Series 54116 - Stainless Steel Flanged Ball Valve Uni-Body Sharpe® polymer-seated, flanged ball valves provide superior performance and reliability in a wide range of applications. Bi-directional, bubble tight shut-off Size Range: NPS 1"-8" (DN...

Solder End High Performance Bronze Ball Valve Lead Free The 585HP is on the cutting edge of manufacturing technology, ease of installation, and highest quality standards. The Classic Ball Valve has been completely rethought and redesigned to enhance the...

SS Compression Ball Valve 3000 WOG 3000 psi @ 200°F 316 stainless steel construction Double ferrule compression tube ends Product Submittal / Data Sheet PDF

SS Compression Ball Valve 6000 WOG 6000 psi @ 200°F 316 stainless steel construction Double ferrule compression tube ends Product Submittal / Data Sheet PDF

SS Compression Check Valve 3000 WOG 3000 psi @ 200°F 316 stainless steel Double ferrule compression tube ends  Viton seal Product Submittal / Data Sheet PDF

Series SM3300ST Stainless Steel 3-PC Threaded Ball Valve Full Port 1/4" thru 2" Working Pressure 1000 WOG Working Temp -4° thru 392° F Blow-out Proof Stem Locking Device Threaded Ends Conform to ASME/ANSI B1.20.1 (NPT) API-598 NACE MR-0175...

Stainless Steel ASME Class 150/300 2-PC Body, Flanged End Ball Valve, Full Port Built-In ISO 5211 Mounting Pad for Easy Automation Anti-Static Devices for Ball-Stem-Body Blow-Out Proof Stem Pressure Balance Hole in Ball Slot Casting Boss on Body for...

Series SM3200ST Stainless Steel Threaded Ball Valve Full Port - 2PC Stainless Body Locking Device Working Pressures: 1/4" - 1" 2000 WOG 1-1/4" - 2" 1500 WOG 2-12" - 3" 1000 WOG Working Temperature: -4°F through 392°F Spec Sheet PDF...

Stainless Steel Three Piece Full Port Socket Weld Ball Valve Full Port - 3PC Stainless Body Locking Device Handle Blowout Proof Stem RTFE Seat Max Pressure: 1000 CWP Catalog PDF Pipe Chart: Common Diameters & Wall Thicknesses PDF

Model CV 91-SS Stainless Steel Center Guided Wafer Type Silent  Features Type: Wafer ASME Class: 150/300 Body: Stainless Steel (A351 Gr. CF8M Type 316) Seats: Stainless Steel (A351 Gr. CF8M Type 316) Trims: Stainless Steel (A351 Gr. CF8M Type 316) ...

Model CV 42-SS Stainless Steel Dual Disc Wafer Check Valve Features Body: Stainless Steel Seats: Metal Discs: Stainless Steel Downloads: Technical Data PDF Installation, Operation & Maintenance PDF Check valves are automatic one-way valves that...

Straight Gas Ball Valve Thread conform to ANSI B1.20.1 Forged Brass body PTFE Ball seat Packing nut, O-ring & packing on the stem seal Leak proof brass stem Aluminum alloy handle Product Spec Sheet PDF

Two-Piece Bronze Ball Valve Full Port Solder End Connections The NIBCO® two-piece ball valve features solder ends for quick and efficient installation. The full port bronze ball valve provides bubble-tight shutoff at 600 PSI. The valve's reinforced...

Two-Piece Bronze Ball Valve Lead Free Full Port Stainless Steel Trim Solder The NIBCO® ball valve is made of lead-free* Silicon Performance Bronze™ alloy and has achieved the stringent NSF/ANSI/CAN 61 section 8 (Commercial Hot) and NSF/ANSI/CAN...

Two-Piece Bronze Ball Valve Solder and Hose Connections The NIBCO® full port bronze ball valve has a solder end connection and hose connection with a hose cap and chain attached. The two-piece valve is ideal for commercial and light industrial...

Two-Piece Bronze Ball Valve Stainless Steel Trim Full Port Solder The NIBCO® bronze ball valve provides bubble-tight shutoff at 600 PSI. The reinforced PTFE seat ring with stainless steel stem and ball exhibit high chemical resistance properties and...

Two-Piece Bronze Ball Valve Threaded UL Listed The NIBCO® bronze ball valve is UL Listed for natural and LP gas and flammable fluid applications. The two-piece valve provides bubble-tight shutoff at 250 PSI. Two-Piece Body Full Port 1/4" - 1"...

Two-Piece Performance Bronze Ball Valve Lead Free Full Port Solder Hose Connection The NIBCO® ball valve is made of lead-free* Silicon Performance Bronze™ alloy and has achieved the stringent NSF/ANSI 61 section 9 and NSF/ANSI 372 listings. The...

Two-Piece Performance Bronze Ball Valve Lead Free Full Port Threaded Hose Connection The NIBCO® ball valve is made of lead-free* Silicon Performance Bronze™ alloy and has achieved the stringent NSF/ANSI 61 section 9 and NSF/ANSI 372 listings...

Wafer Butterfly Valve 300 PSI Connections: Wafer Ends (ANSI Class 125) Sizes: 2-1/2”, 3”, 4”, 6”, 8” Approvals: UL, ULC, FM, and California State Fire Marshal Maximum Working Pressure: 300PSI (Max. Test Pressure: 600PSI)...

Series 550BEG Wafer Style Butterfly Valve Gear Operator DI Body Aluminum Bronze Disc EPDM Seat Spec Sheet PDF Pipe Chart: Common Diameters & Wall Thicknesses PDF Certificate of Conformance PDF

Wafer Butterfly Valve - Gear Operator Stainless Steel Shaft & Disc EPDM Seats Ductile Iron Body 200 PSI Rating Gear Operator ISO 5211 Mounting Pad API 609 Download Catalog PDF     Engineering Data PDF   ...

Series 35116 - Stainless Steel Cast Flanged Gate Valves Sharpe® metal-seated, cast, flanged gate valves provide superior performance and reliability in a wide range of applications. Outside Screw and Yoke (OS&Y) - Rising Stem Design...
