Shurjoint

7043 Flange Adapter - ANSI Class 300

(No reviews yet) Write a Review
SKU:
7043
Availability:
Usually ships in 24 hours.
Weight:
0.00 LBS
*Images are for visual reference only.
  • 7043 Flange Adapter ANSI Class 300
  • 7043 Flange Adapter ANSI Class 300 Data Sheet
$126.33 - $680.90

Represents the combined quantity sold of all the sizes under this product SKU.
Sold:

Description

7043 Flange Adapter - ANSI Class 300

The Model 7043 flange adapter allows for a direct connection with ANSI Class 300 flanges. The specially designed gasket enables the transition from a grooved system to a flanged system or component with this single flange. 2” through 8” Model 7043 flange adapters are supplied hinged as a single assembly, while larger sizes are supplied with separate segments. The Model 7043 flange adapters are comprised of two identical ductile iron segments complete with an
EPDM gasket and two pairs of bolts and nuts. The flange segments are painted black. The Model 7043 flange adapter has been designed with small projections on the outside face of the flange for mating with 1/16” (1.6 mm) raised face flanges. For mating with flat-face flanges these projections must be removed, this can be accomplished with a grinder or other tool.
