Dixon
W8F8 - W-Series Wingstyle Female Threaded Plug
- SKU:
- W8F8
- Availability:
- Usually Ships Within 24 Hours
- Weight:
- 1.02 LBS
*Images are for visual reference only.
Description
Details
Compatibility & Interchange Data
- Aeroquip 5100-Series, Parker 6100-Series
- Snap-Tite 78-Series, Faster Series-FB, Safeway S51-Series
Construction
- Machined components are manufactured using solid steel and brass bar stock.
- Stainless steel retaining rings and springs maximize corrosion resistance and extend service life.
- Steel componentry is plated using ROHS Compliant Trivalent Chrome.
- For steel models, coupler valve sleeve and nipple valve are constructed of brass
- Nitrile (Nitrile Rubber) seals are standard, providing a temperature range of -40°F to +250°F (-40°C to +121°C).
- Couplings have a TPC-ET back-up ring on the valve sleeve to extend service life.
- Nipple valve seal is crimped to improve seal integrity and prolong service life.
- External O-ring on plug indicates full connection and acts as a contamination shield in connected mode.
- Redundant O-Ring on the coupler body will engage nipple for secondary sealing support.
Features
- Full Hex - Ease of Installation
- Vane Valve Guide - Improved Flow Performance
- Compact Body Profile - Reduction of Side-Load Stress
- O-Ring 'Full-Connection' Indicator - Improved Connection Efficiency
- Swaged Valve Seal - Resistance to Flow Damage
Safety Notes
- Although wingstyle couplings are able to connect and disconnect while under pressure, it is recommended that hydraulic power supply be de-energized during connection to ensure operator safety. If it is not possible to de-energize the circuit, operators must be aware of their surroundings to ensure that an attachment or tool does not put them at risk, once hydraulic power is applied during the connection process.
- W-series couplings are not recommended for continuous hydraulic impulse applications at rated pressures.
WARNING: This product contains lead, a chemical known to the State of California to cause cancer and birth defects or other reproductive harm.
