Dixon
DVF-A40GE - KF Centering Ring Vacuum Fitting Assembly
(No reviews yet)
Write a Review
- SKU:
- DVF-A40GE
- Availability:
- Usually Ships Within 24 Hours
- Weight:
- 0.08 LBS
*Images are for visual reference only.
Description
Details
Applications
Vacuum sealing for ½" - 2" OD tubing in the semiconductor industry
Construction
- Fittings: 304 or 316L stainless steel
- Clamps: aluminum
- O-ring: FKM
Features
- Each assembly contains two identical flanges and a centering ring assembly and is clamped together with a thumbscrew clamp
- Coupling features prevent O-ring collapse and keep the assembly aligned
- KF flanges are compatible with other ISO-KF-QF vacuum flange manufacturers' components
- All fittings are IPA cleaned and bagged in a controlled environment
- MTR's available
Specifications
- Maximum temperature: 302°F (150°C)
- Helium leakage testing to 1x10-8 Torr
- Standards followed: ISO2681
