DC Drive Reversing Motor Controller For BP10
- SKU:
- 10RIIKBPB125
- Availability:
- Allow 2-3 Days to Ship
- Weight:
- 2.20 LBS
*Images are for visual reference only.
Description
DC Drive Reversing Motor Controller For BP10
The KBPB-125 is a solid-state DC motor drive designed for robust control of permanent magnet (PM) and shunt wound DC motors. Built to provide instant anti-plug reversing, dynamic braking, and rapid cycling, this drive combines proven control technology with flexible speed adjustment features.
- Reversing DC Motor Drive For PM And Shunt Wound Motors
- Input: 115 VAC, 50/60 Hz
- Output: 90 VDC Armature
- Horsepower: Up To 3/4 HP (No Heatsink), Up To 1.5 HP (With Heatsink)
- Current Rating: 8–12 A (Configuration Dependent)
- Solid-State Anti-Plug Reversing With Dynamic Braking
- Adjustable Trimpots: Min/Max Speed, Current Limit, Accel/Decel
- Requires External HP Resistor And Armature Fuse (Sold Separately)
