Titan
Cast Bronze Y Strainer - Threaded or Solder - Class 125
- SKU:
- YS55-56BZ
- Availability:
- Usually in Stock – Ships Quickly
- Weight:
- 0.00 LBS
Description
Cast Bronze Y Strainer - Threaded or Solder - Class 125
Titan Flow Control cast bronze Y strainers provide compact debris protection for compatible plumbing, mechanical, and industrial piping systems. This GetPipe listing combines Titan YS55-BZ threaded strainers and YS56-BZ solder-end strainers so you can select both the required nominal size and end connection.
Select the nominal pipe size and end connection from the product options above. The selected combination determines the Titan part code, online selling price, weight, net cost, pressure rating, and product configuration.
Product Highlights
- Cast bronze C84400 body - ASTM B584
- ASME Class 125
- Choose threaded or solder end connections
- YS55-BZ threaded: 200 psi WOG non-shock at 150°F
- YS56-BZ solder, 1/4" through 1-1/2": 400 psi WOG non-shock at 100°F
- YS56-BZ solder, 2" through 3": 315 psi WOG non-shock at 100°F
- Large straining capacity
- Precision-machined screen seats
- Self-cleaning capability with appropriate blow-off arrangement
- Threaded cap for screen access
- Sizes 1/4" through 3"
Technical Specifications
| Manufacturer | Titan Flow Control |
|---|---|
| Models | YS55-BZ Threaded / YS56-BZ Solder |
| Body Material | Cast Bronze C84400 - ASTM B584 |
| Configuration | Y / Wye Strainer |
| End Connections | Threaded or Solder |
| Pressure Class | ASME Class 125 |
| YS55-BZ Threaded Rating | 200 psi WOG non-shock at 150°F |
| YS56-BZ Solder Rating - 1/4" through 1-1/2" | 400 psi WOG non-shock at 100°F |
| YS56-BZ Solder Rating - 2" through 3" | 315 psi WOG non-shock at 100°F |
| Stocked Screen / Perforation Material | Type 304 Stainless Steel |
| Available Sizes | 1/4" through 3" |
Choose the Correct End Connection
Threaded - YS55-BZ
Choose the threaded model when the piping system uses compatible threaded connections. Titan rates the YS55-BZ at 200 psi WOG non-shock at 150°F across the 1/4" through 3" size range.
Solder - YS56-BZ
Choose the solder model for compatible solder-joint piping. Titan rates sizes 1/4" through 1-1/2" at 400 psi WOG non-shock at 100°F and sizes 2" through 3" at 315 psi WOG non-shock at 100°F.
Screen & Perforation Options
Titan stocks Type 304 stainless steel mesh and perforation selections for these bronze Y strainers. Stocked mesh selections include 10, 20, 30, 40, 60, 80, and 100 mesh, along with multiple perforation sizes. Contact GetPipe.com when a specific filtration opening is required.
Common Applications
Plumbing & Mechanical
- Water piping
- Pump protection
- Meter protection
- Valve protection
Commercial & Industrial
- Compatible process piping
- Equipment inlet protection
- Spray nozzle protection
- Maintenance and replacement applications
Manufacturer Resources
Need Help Selecting a Titan Bronze Y Strainer?
Our industrial PVF specialists can help confirm nominal pipe size, threaded versus solder connection, pressure requirements, screen selection, media compatibility, and product availability.
Frequently Asked Questions
What is the difference between YS55-BZ and YS56-BZ?
YS55-BZ uses threaded end connections. YS56-BZ uses solder end connections. Both are cast bronze Class 125 Y strainers.
Are the pressure ratings the same?
No. The threaded YS55-BZ is rated 200 psi WOG non-shock at 150°F. The solder YS56-BZ is rated 400 psi WOG at 100°F through 1-1/2" and 315 psi WOG at 100°F for 2" through 3".
What screen material does Titan use for stocked configurations?
Titan identifies Type 304 stainless steel for stocked mesh and perforation selections.
Can I order a different mesh or perforation?
Yes. Titan stocks several mesh and perforation options. Contact GetPipe.com to confirm the correct filtration opening.
Important Ordering Notes
- Select both nominal pipe size and end connection before adding the product to your cart.
- Threaded selections use Titan YS55-BZ part codes; solder selections use Titan YS56-BZ part codes.
- Pressure ratings differ between threaded and solder configurations.
- Confirm pressure, temperature, media compatibility, joining method, screen selection, and applicable code requirements before installation.
