Pro-Flex
Pro-Flex 3/4" ID x 1" OD Gas Appliance Connector - 3/4" MIP x 3/4" FIP
- Availability:
- Usually Ships in 5-7 Business Days
- Weight:
- 0.00 LBS
Description
Pro-Flex 3/4" ID x 1" OD Gas Appliance Connector - 3/4" MIP x 3/4" FIP
Pro-Flex 3/4" ID x 1" OD Gas Appliance Connectors provide a flexible connection solution for compatible gas appliances requiring a 3/4" MIP x 3/4" FIP connection configuration. This larger-diameter connector family features a 3/4" inside diameter and 1" outside diameter for applications requiring greater gas-flow capacity than smaller appliance connectors.
Available in 18", 24", 36", and 72" lengths, these connectors provide multiple installation options while maintaining the same tube diameter and end-connection configuration throughout the product family.
Product Highlights
- Flexible gas appliance connector
- 3/4" inside diameter
- 1" outside diameter
- 3/4" MIP x 3/4" FIP connection configuration
- Larger-diameter design for compatible higher-demand gas appliances
- Available in 18", 24", 36", and 72" lengths
- Multiple length options for different installation layouts
- Flexible construction simplifies final appliance connections
- Manufactured by Pro-Flex
Technical Specifications
| Manufacturer | Pro-Flex |
|---|---|
| Product Type | Flexible Gas Appliance Connector |
| Inside Diameter | 3/4" |
| Outside Diameter | 1" |
| Connection - End 1 | 3/4" MIP |
| Connection - End 2 | 3/4" FIP |
| Available Lengths | 18", 24", 36", and 72" |
| Estimated Weight Range | Approximately 0.80-1.80 lb, depending on length |
Available Sizes
| Part Number | Tube Size | Length | Est. Weight |
|---|---|---|---|
| PFAC-34C-34-18 | 3/4" ID x 1" OD | 18" | 0.80 lb |
| PFAC-34C-34-24 | 3/4" ID x 1" OD | 24" | 0.95 lb |
| PFAC-34C-34-36 | 3/4" ID x 1" OD | 36" | 1.15 lb |
| PFAC-34C-34-72 | 3/4" ID x 1" OD | 72" | 1.80 lb |
Larger-Diameter Gas Appliance Connection
3/4" ID Connector
The 3/4" inside diameter provides a larger flow path than smaller appliance connector sizes, making this connector family suitable for compatible gas appliances with greater fuel-demand requirements.
Flexible Installation
Flexible construction helps simplify the final connection between compatible gas-supply piping and the appliance while accommodating common installation layouts.
Available Connector Lengths
Standard Lengths
- 18"
- 24"
- 36"
Extended Length
- 72"
The extended 72" option provides additional reach for installations where the appliance connection is located farther from the gas supply.
Consistent Tube Size Across All Variants
Every connector in this product family uses the same 3/4" ID x 1" OD tube size and 3/4" MIP x 3/4" FIP connection configuration. Connector length is the primary difference between the four available variants.
Connection Configuration
3/4" MIP Connection
One end provides a 3/4" male iron pipe connection for connection to compatible gas-supply or appliance piping.
3/4" FIP Connection
The opposite end provides a 3/4" female iron pipe connection, creating a 3/4" MIP x 3/4" FIP configuration.
Selecting the Correct Length
Select the connector length according to the required distance between the gas supply and appliance. This family is available in 18", 24", 36", and 72" lengths while maintaining the same 3/4" ID x 1" OD tube size and 3/4" MIP x 3/4" FIP connection configuration.
Common Applications
Larger Gas Appliances
- Compatible high-demand gas appliances
- Commercial cooking equipment
- Larger residential gas appliances
- Replacement appliance connections
Flexible Gas Connections
- Final appliance connections
- Commercial mechanical installations
- Residential mechanical installations
- Other compatible gas equipment
Installation Considerations
- Confirm the required connector length before ordering.
- Verify that the installation requires a 3/4" ID connector.
- Confirm that the 3/4" MIP x 3/4" FIP connection configuration matches the installation.
- Verify appliance and gas-supply connection sizes before installation.
- Confirm that the connector provides sufficient capacity for the connected appliance.
- Do not kink, crush, stretch, or excessively bend the connector.
- Use only in applications suitable for the connector and fitting configuration.
- Installation must comply with applicable fuel-gas codes and manufacturer requirements.
- Installation should be completed by qualified personnel familiar with fuel-gas systems.
Need Help Selecting a Gas Appliance Connector?
Our industrial PVF specialists can help review the required connector diameter, end connections, length, and appliance application before you order.
Frequently Asked Questions
What size is this Pro-Flex gas appliance connector?
Every connector in this product family has a 3/4" inside diameter and 1" outside diameter.
What is the connection configuration?
This connector family uses a 3/4" MIP x 3/4" FIP connection configuration.
What lengths are available?
Available lengths are 18", 24", 36", and 72".
Do all lengths use the same tube size?
Yes. All four variants use the same 3/4" ID x 1" OD connector size.
Which SKU is the 18" connector?
The 18" version is Pro-Flex part number PFAC-34C-34-18.
Which SKU is the 36" connector?
The 36" version is Pro-Flex part number PFAC-34C-34-36.
Which SKU is the 72" connector?
The 72" version is Pro-Flex part number PFAC-34C-34-72.
How much does the connector weigh?
Estimated individual weights range from approximately 0.80 lb for the 18" connector to approximately 1.80 lb for the 72" connector. These are estimated weights for product and shipping setup rather than manufacturer-published specifications.
How do I choose the correct connector length?
Measure the required connection distance and select an appropriate available length while confirming that the tube size and 3/4" MIP x 3/4" FIP fitting configuration match the appliance and gas supply.
Important Ordering Notes
- All variants use a 3/4" ID x 1" OD connector.
- Connection configuration: 3/4" MIP x 3/4" FIP.
- Available lengths are 18", 24", 36", and 72".
- Select the correct connector length before ordering.
- Verify appliance and gas-supply connection requirements before ordering.
- Confirm adequate connector capacity for the connected appliance.
- Variant weights shown are estimated values for product and shipping setup.
- Installation must comply with applicable fuel-gas codes and manufacturer requirements.
