Milwaukee Tool EXACT Rapid Reset 1-1/8" Draw Stud Set
- SKU:
- MLW49-16-2704
- Availability:
- Usually Ships Same Day
- Weight:
- 1.49 LBS
Description
DUTY®
1-1/8 in
Rapid Reset Stud
Build a 2-1/2–4 in conduit-punch setup with the 1-1/8 in rapid-reset draw stud.
Product Overview
For the 2676-20, this stud serves 2-1/2–4 in conduit punch sizes; stud diameter differs.
The 1-1/8 in stud needs Quick Connect; a quarter-turn ball-pull release aids slug removal.
- Stud diameter1-1/8 in connection size.
- 2676-20 conduit fit2-1/2–4 in punch sizes.
- Quarter-turn resetBall-pull slug release.
- Required setupQuick Connect assembly.
Technical Specifications
- Stud size
- 1-1/8 in
- Conduit sizes
- 2-1/2–4 in
- Pilot hole
- 1-1/4 in
- Tool reference
- 2676-20
- Connection
- Rapid Reset
- Mounting
- Quick Connect required
Choose the Correct Fit
Use the manual’s exact 2-1/2–4 in conduit punch/die rows. The 1-1/8 in stud size is not the finished hole size.
Keep the Quick Connect assembly fitted; Rapid Reset studs cannot be mounted directly into the piston.
Installation & Care
Prepare the 1-1/4 in pilot hole specified for this stud diameter. Remove the battery before assembling the cutting components.
Inspect threads and locking surfaces before each setup. Keep fingers away from the punch and die and clear the slug after cutting.
Small Details. Big Jobsite Energy.
Get set. Stay focused. Make your next move count.
THE NEXT JOB.
Ask Willy:
Need a draw-stud match? Give Willy the tool model, punch and die part numbers, and the conduit opening you need.
Important Product Questions
Is this a complete knockout cutting set?
The draw stud connects the cutting components. Match it with the correct punch, die and tool; these parts are not interchangeable solely by nominal size.
Can it mount directly in the tool?
No. The 2676-20 manual requires its Quick Connect assembly for Rapid Reset studs.
What does the conduit range describe?
It identifies the 2-1/2–4 in conduit punch sizes listed with this stud in the 2676-20 table. It does not specify sheet thickness or finished hole diameter.
