Milwaukee
Milwaukee Tool 3/4" Ball Bearing Draw Stud
- SKU:
- MLW49-16-2622
- Availability:
- Usually Ships Same Day
- Weight:
- 0.75 LBS
Description
DUTY®
3/4" Ball-Bearing
Draw Stud
Replace the 3/4-inch ball-bearing draw stud used in the EXACT hand-ratchet knockout setup.
Product Overview
The hexagonal base provides wrench engagement while the threaded shaft carries the punch.
A short unthreaded lead projects beyond the working threads; inspect both before assembly.
- Stud size3/4 inch
- Bearing designBall-bearing assembly
- Tool engagementHexagonal base
- Thread leadUnthreaded end section
Technical Specifications
- Stud size
- 3/4 in
- Bearing type
- Ball bearing
- Set relationship
- EXACT 49-16-2694
- Wrench interface
- Hexagonal base
- Thread form
- External
- Lead end
- Unthreaded
Choose the Correct Fit
Match the 3/4-inch stud to the punch, die and hand-ratchet setup. Do not choose the draw stud from conduit size alone.
Milwaukee lists this stud in EXACT hand-ratchet set 49-16-2694. Confirm other tool or set applications separately.
Installation & Care
Inspect the working threads, bearing and wrench-contact surfaces before use. Replace damaged components rather than forcing a binding punch.
Follow the knockout instructions for setup and lubrication. Keep hands clear of the punch and die and avoid using extra leverage not approved for the tool.
Small Details. Big Jobsite Energy.
Get set. Stay focused. Make your next move count.
THE NEXT JOB.
Ask Willy:
Tell Willy the knockout set, punch and die numbers to help confirm the matching ball-bearing draw stud.
Important Product Questions
Which set is this stud listed with?
Milwaukee lists it as a component of EXACT 49-16-2694, the 1/2-inch to 2-inch hand-ratchet knockout set.
Does the stud size describe the finished hole?
No. The draw-stud size identifies the accessory connection. The selected punch and die determine the hole size.
What should I inspect before use?
Check the threads, bearing and hexagonal base for wear or damage, and confirm the complete punch-and-die assembly matches the knockout instructions.
