150 lb. Ductile Iron Flanged 11-1/4 Elbow
- SKU:
- 38EL1
- Availability:
- Usually Ships Same Day
- Weight:
- 0.00 LBS
Description
150 lb. Ductile Iron Flanged 11-1/4 Elbow
ASC / SCI FIG 38EL1 150 lb. Ductile Iron Flanged 11-1/4 Elbow provides a gradual 11-1/4° change in direction for compatible flanged piping systems where only a small directional adjustment is required.
Manufactured from ductile iron conforming to ASTM A536, FIG 38EL1 is part of the SCI Class 150 flanged fitting family with applicable dimensions conforming to ASME B16.42 and ANSI/AWWA C110/A21.10.
Product Highlights
- ASC / SCI FIG 38EL1
- 11-1/4° elbow configuration
- Class 150 ductile iron
- Flanged end connections
- UL Listed through 12"
- Galvanizing available upon request
Technical Specifications
| Product Type | Flanged 11-1/4° Elbow |
|---|---|
| Brand | ASC / SCI |
| Figure | 38EL1 |
| Fitting Class | Class 150 |
| Configuration | 11-1/4° Elbow |
| Connection Type | Flanged x Flanged |
| Material | Ductile Iron |
| Material Standard | ASTM A536 |
| Flanged Fitting Standard | ASME B16.42 |
| Waterworks Standard | ANSI/AWWA C110/A21.10 |
| Listing | UL Listed Through 12" |
| Optional Finish | Galvanizing Available Upon Request |
Construction Details
FIG 38EL1 is manufactured from ductile iron conforming to ASTM A536 for strength and durability in compatible flanged piping installations.
The 11-1/4° elbow configuration provides a slight directional change while maintaining flanged connections at both ends. This makes it useful where piping alignment requires less correction than a conventional 22-1/2°, 45°, or 90° elbow.
SCI identifies its flanged fitting family as UL Listed through 12 inches. Galvanizing is also available upon request for applications requiring an alternate protective finish.
Design & Typical Applications
11-1/4° Elbow Design
- Gradual directional change
- Flanged end connections
- Ductile iron construction
- Serviceable bolted joints
- Compact alignment fitting
Typical Applications
- Water distribution systems
- Industrial piping
- Mechanical piping systems
- Pump and valve piping
- Utility piping systems
Installation & Selection Considerations
- Confirm the required flange size.
- Verify the 11-1/4° angle.
- Use compatible flange gaskets.
- Support adjoining piping properly.
- Confirm system service requirements.
Use the supplied flange specifications and SCI Ductile Iron Flanged Fittings catalog to review flange information, FIG 38EL1 product details, material requirements, and selection information.
Need Help Selecting a Ductile Iron Flanged 11-1/4° Elbow?
Need help confirming flange size, fitting angle, material requirements, gasket selection, or compatibility with your piping system? The GetPipe.com Team can help.
Frequently Asked Questions
What is the figure number for this 11-1/4° elbow?
The ASC / SCI 150 lb. Ductile Iron Flanged 11-1/4° Elbow is FIG 38EL1.
What is an 11-1/4° elbow used for?
It provides a small directional change in a flanged piping run where a sharper elbow angle is not required.
What connections does FIG 38EL1 use?
FIG 38EL1 uses flanged connections on both ends for joining compatible flanged piping components.
What material is FIG 38EL1 made from?
FIG 38EL1 is manufactured from ductile iron conforming to ASTM A536.
What standards apply to the flanged fitting?
Applicable SCI ductile iron flanged fitting dimensions conform to ASME B16.42 and ANSI/AWWA C110/A21.10.
Is the flanged elbow UL Listed?
SCI identifies its flanged fitting family as UL Listed through 12 inches.
Can this elbow be galvanized?
Yes. ASC / SCI identifies galvanizing as available upon request.
What should I confirm before ordering?
Confirm flange size, 11-1/4° configuration, mating flange requirements, gasket selection, and intended system service.
Important Ordering & Installation Notes
- Confirm the required flange size.
- Verify the 11-1/4° configuration.
- Use compatible flange gaskets.
- Align mating flanges properly.
- Confirm intended system service.
